FD 210-22 DS G 1/2
Mfr # FD 210-22 DS G 1/2
Zoro # G611208076
product price:Â
$
404.99
/ea
Free Shipping & Returns
Key Features
Height - Compressed
100 mm
Operating Pressure - Maximum
120 psi
Spring Rate - Maximum
218.5 N/mm
Maximum Dynamic Load Capacity
11.5 kN @ 5 bar, 13.9 kN @ 6 bar, 16.3 kN @ 7 bar, 18.7 kN @ 8 bar, 6.7 kN @ 3 bar, 9.2 kN @ 4 bar
Air Inlet Thread Size
1/2 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- FD 210-22 DS G 1/2
- Zoro #
- G611208076
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Height - Compressed
- 100 mm
- Air Inlet Thread Size
- 1/2 in
- Mounting Hole Size
- 10 mm
- Compressed Diameter - Maximum
- 270 mm
- Height - Full Stroke
- 250 mm
- Mounting Plate Diameter - Top
- 181 mm
- Mounting Plate Diameter - Bottom
- 181 mm
Details
- Operating Pressure - Maximum
- 120 psi
- Spring Rate - Maximum
- 218.5 N/mm
- Maximum Dynamic Load Capacity
- 11.5 kN @ 5 bar, 13.9 kN @ 6 bar, 16.3 kN @ 7 bar, 18.7 kN @ 8 bar, 6.7 kN @ 3 bar, 9.2 kN @ 4 bar
- Number of Mounting Holess
- 8
- Operating Temperature - Minimum
- -76 Degrees F
- Air Spring Material
- Natural Rubber
- Item
- Double Convolution Air Actuator
- Operating Pressure - Minimum
- 0 psi
- Spring Rate - Minimum
- 100 N/mm
- Natural Frequency
- 1.9 Hz
- Operating Temperature - Maximum
- 158 Degrees F
- Mounting Hole Center to Center Distance
- 181 mm
- Air Spring Type
- Double Convoluted
- Air Inlet Location
- Center
- Installation Space Required
- 300 mm
- System of Measurement
- Metric
Description
Double Convolution Air Actuator, Air Inlet Location Center, Air Inlet Thread Size 1/2 in, Air Spring Material Natural Rubber, Air Spring Type Double Convoluted, Compressed Diameter - Maximum 270 mm, Height - Compressed 100 mm, Height - Full Stroke 250 mm, Installation Space Required 300 mm, Maximum Dynamic Load Capacity 11.5 kN @ 5 bar, 13.9 kN @ 6 bar, 16.3 kN @ 7 bar, 18.7 kN @ 8 bar, 6.7 kN @ 3 bar, 9.2 kN @ 4 bar, Mounting Hole Center to Center Distance 181 mm, Mounting Hole Size 10 mm
