Culligan

Filter Housing, 15-1/2" H, 6-1/2" W

product price: $54.89
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Height (In.) 15 1/2 in
  • Width (In.) 6 1/2 in
  • Max. Pressure (PSI) 125 psi
  • Housing Material Styrene Acrylonitrile
  • Head Material Polypropylene
See all product information

Product Information

  • Brand Culligan
  • MFR # WH-S200-C
  • Zoro # G7781658
  • UPC #
    033663007291
  • Country of Origin Taiwan, Province of China
  • Category Filter Housings

Dimensions

Height (In.) 15 1/2 in
Width (In.) 6 1/2 in
Dia. (In.) 6 3/4 in
Length (In.) 5 7/16 in
Size 3/4 in NPT
Width 6 1/2 in
Height 15 1/2 in
Connection Size 3/4 in
Depth 5 3/8 in
Overall Height 15 1/2 in

Details

Max. Pressure (PSI) 125 psi
Housing Material Styrene Acrylonitrile
Head Material Polypropylene
Inputs/Outputs 3/4 in NPT
Max. Flow GPM 4
Standards NSF 372, NSF 61
Microns 5
Color Clear
Service Life (Gallons) 8,000
Type Filter Housing
Compliance WQA
Cartridges Required 1
Max. Temp. (F) 100 Degrees F
Flow Rate (GPM) 4
Item Water Filtration System
For Use With CW-F, CW-MF, Mfr. No. P5, P1, S1A, SCWH-6
Reduces Coarse Sand, Dirt, Rust, Scale, Sediment, Silt
Includes Cartridge, Clear Sump, Filter Life Monitor with Pre-Installed Timer Battery, Housing Wrench, Mounting Bracket and Screws, Standard 3/4 in Inlet Outlet Valve in Head Cap
Application Household Appliances
Flow Rate 4 gpm
Maximum Temperature 100 Degrees F
Connection Type NPT
Maximum Pressure 125 psi
Minimum Pressure 30 psi
Micron Rating 5 micron
Service Life 8,000 gal
Minimum Temperature 40 Degrees F
Compatible Mfr. Model Number CW-F, CW-MF, P1, P5, S1A, SCWH-6

Description

Water Filtration System, Reduces Coarse Sand, Dirt, Rust, Scale, Sediment, Silt, Micron Rating 5 micron, Connection Size 3/4 in, Overall Height 15 1/2 in, Width 6 1/2 in, Service Life 8,000 gal, Flow Rate 4 gpm, Application Household Appliances, Color Clear, Compatible Mfr. Model Number CW-F, CW-MF, P1, P5, S1A, SCWH-6, Compatible with Grainger Part Number 29AH42, 29AH43, 29AH44, 29AH45, 29AH46, Connection Type NPT, Depth 5 3/8 in, Head Material Polypropylene

Restrictions

  • *** This is a restricted item in CA, LA, MD, VT. It cannot be used for potable water applications.
