Shop DAYTON

Definite Purpose HVAC Motor, 7/32 hp

  • Mfr # VEGGS45909G

  • Zoro # G9678532

product price:
$
171.99
/ea
Free Shipping & Returns

Key Features

For Use With Mfr. Model Number
31XL41
Fits Brand
Dayton
For Use With
Grainger Item Number: 31XL41
Length Less Shaft
4 5/8 in
Capacitor Required
Capacitor Not Required
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
VEGGS45909G
Zoro #
G9678532
UPC #
190735259450
Country of Origin
Multiple
For Use With Mfr. Model Number
31XL41
Fits Brand
Dayton
Item
BLDC Motor
For Use With
Grainger Item Number: 31XL41
Capacitor Required
Capacitor Not Required
Frequency
60/50 Hz
Full Load Current @ 50 Hz
3.4A
Insulation Class
A
Nominal Efficiency
74 %
Frame Material
Steel
Motor Shaft Rotation
CW/CCW
Compatible Brand
Dayton
Compatible Manufacturer Part Number
31XL41
Ambient Temperature - Maximum
40 Degrees C
Duty
Continuous
Mounting Position
Horizontal
Bearing Type
Ball
Manufacturers Warranty
1 yr
Nameplate Service Factor @ 50 Hz
1
Product Type
Definite Purpose HVAC Motor
Sub Application
Fan/Blower
Motor Thermal Protection
Auto
Usable @ 200V
Not Usable at 200V
Weight
2.34 kg
Usable @ 208V
Not Usable at 208V
Motor Enclosure Type
Totally Enclosed Air-Over
Nameplate Service Factor @ 60 Hz
1
Shaft Design
Flat
Drive Type
Direct Drive
Nameplate RPM @ 50 Hz
1200 RPM
Application
Fan/Blower
Standards
UL (E469818)
Number of Shafts
1
Phase
Single
Nameplate Voltage @ 50 Hz
115V AC
Full Load Current @ 60 Hz
3.4A

Description

Definite Purpose HVAC Motor, Single Phase, 7/32 hp HP, Nameplate RPM 1,200 RPM, Voltage 115V AC, Full Load Amps 3.4A, Non-Standard Frame, OEM Replacement Brand Dayton, Usable @ 208V Not Usable at 208V, Usable @ 200V Not Usable at 200V, 60/50 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class A, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Lug
