Exhaust Fan, 16In Bl, Alum, 115V

Mfr # 10D956
Zoro # G4039271

$275.99

Free Shipping & Returns

Key Features

Bearing Type

Sleeve

Agency Compliance

UL and cUL Listed, AMCA

Fiberglass Wall Shutter No.

5C212

Galvanized Wall Shutter No.

1C743

Frame Finish

Galvanized

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: 10D956
Zoro #: G4039271
UPC #: 190735108819
Country of Origin: China

Dimensions

Outside Dia. (In.): 20 in
Max. Depth (In.): 7 3/4 in
Height (In.): 20 in
Blade Dia.: 16 in
Dimension B (In.): 5 in
Dimension C (In.): 2 1/8 in
Flange Width (In.): 1 in
Inside Dia. (In.): 16 3/8 in
Dimension A (In.): 20 in
Venturi Clearance Dia. (In.): 16 7/16 in
Venturi Depth (In.): 2 3/4 in
Dimension D (In.): 16 3/8 in
Width (In.): 20 in
Overall Height: 20 in
Overall Width: 20 in
Venturi Depth: 3 in
Flange Width: 1 in
Blade Diameter: 16 in
Overall Diameter: 20 in
Duct Diameter: 16 1/2 in
For Cut-Out Diameter: 16 1/2 in
Venturi Diameter: 16 1/2 in
Overall Depth: 7 3/4 in

Details

Item: Exhaust Fan
Bearing Type: Sleeve
Agency Compliance: UL and cUL Listed, AMCA
Fiberglass Wall Shutter No.: 5C212
Galvanized Wall Shutter No.: 1C743
Frame Finish: Galvanized
For Use With: General Ventilation Applications
Fan Voltage: 115V AC
Sones @ 0.000-In. SP @ 5 Ft.: 10.2
Drive Package Included: No
Aluminum Wall Shutter No.: 4C557
CFM @ 0.125-In. SP: 1,045 cfm
Voltage: 115
Max. Ambient Temp. (F): 104 Degrees F
CFM @ 0.250-In. SP: 704 cfm
Full Load Amps: 1
Sones @ 0.125-In. SP @ 5 Ft.: 13.6
Number of Blades: 3
Hz: 60
Wire Guard Finish: Zinc Plated
Exhaust/Supply Fan Item: Exhaust Fan
Frame Material: Steel
CFM @ 0.000-In. SP: 1,334 cfm
CFM @ 0.375-In. SP: 490 cfm
Exhaust/Supply Fan Motor HP: 1/20 hp
Guard Material: Steel
Motor RPM: 1,650 RPM
Type: Medium Duty Direct Drive
Motor Insulation: Class B
Speed Control: 48C172
Motor Enclosure: Totally Enclosed Air Over
Phase: 1
Mounting Position: Vertical
Watts: 80 W
Propeller Material: Aluminum
Standards: AMCA, UL and cUL Listed
Duct Shape: Round
Ventilation Type: Exhaust
Wattage: 82 W
Guard Type: Intake
Assembled: Assembled
Includes Dehumidistat: No
Nameplate Voltage: 115V AC
Speed Controllable: Yes
Noise Level @ 0.000 in SP @ 5 ft: 10.2 sones
Number of Speeds: 1
Motor Horsepower: 1/20 hp
Maximum Ambient Operating Temperature: 104 Degrees F
Blade Material: Aluminum
Exhaust Airflow @ 0.000 in SP: 1,334 cfm
Electrical Connection: Hardwired
Noise Level @ 0.125 in SP @ 5 ft: 14 sones
Exhaust Airflow @ 0.250 in SP: 704 cfm
Exhaust Airflow @ 0.100 in SP: 1,045 cfm
Vent Design: Ductless
Fan Style: Panel
Exhaust Airflow @ 0.375 in SP: 490 cfm
Motor Speed: 1,650 RPM
Drive Type: Direct Drive
Guard Finish: Zinc Plated
Includes Motor: Yes
Maximum Noise Level: 10.2 sones
Exhaust Airflow @ 0.125 in SP: 1,045 cfm
Method of Construction: Stamped

Description

Exhaust Fan, Assembled Assembled, Blade Diameter 16 in, Blade Material Aluminum, Drive Type Direct Drive, Duct Diameter 16 1/2 in, Exhaust Airflow @ 0.000 in SP 1,334 cfm, Frame Finish Galvanized, Frame Material Steel, Guard Finish Zinc Plated, Guard Material Steel, Guard Type Intake, Includes Dehumidistat No, Maximum Noise Level 10.2 sones
