  9. High Pressure Blower, 5 HP, 3 Phase
Dayton High Pressure Blower, 5 HP, 3 Phase 48LX17 - main

High Pressure Blower, 5 HP, 3 Phase

  • Mfr # 48LX17

  • Zoro # G4150968

product price: $1,629.99
/ea
Item requires special delivery charges. A $125.00 per item surcharge will be applied.

Key Features

Type
With Motor
Wheel Dia. (In.)
13 1/2 in
Voltage
208-230/460
Motor HP
5 hp
Housing Material
Steel
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
48LX17
Zoro #
G4150968
UPC #
-
Country of Origin
Canada

Dimensions

Wheel Dia. (In.)
13 1/2 in
Dimension S (In.)
8 1/8 in
Dimension F (In.)
9 9/16 in
Dimension C (In.)
7 1/8 in
Dimension T (In.)
15 in
Dimension L (In.)
11 in
Wheel Width (In.)
4 3/8 in
Dimension J (In.)
9 5/8 in
Dimension A (In.)
17 5/8 in
Depth (In.)
18 7/8 in
Dimension P (In.)
8 in
Dimension G (In.)
1 in
Dimension H (In.)
10 1/2 in
Discharge Width (In.)
5 3/4 in
Dimension E (In.)
8 in
Dimension B (In.)
11 1/4 in
Dimension X (In.)
12 5/8 in
Dimension K (In.)
11 3/8 in
Dimension R (In.)
11 1/2 in
Inlet Dia. (In.)
8 in
Dimension D (In.)
5 3/4 in
Dimension V (In.)
7 1/4 in
Shaft Dia. (In.)
1 1/8 in
Discharge Height (In.)
7 1/8 in
Width (In.)
22 3/8 in
Height (In.)
23 1/8 in
Wheel Bore Diameter
1 1/8 in
Housing Depth
18 7/8 in
Wheel Diameter
13 1/2 in
Overall Height
23 1/8 in
Outlet Height
7 1/8 in
Overall Width
22 3/8 in
Shaft Diameter
1 1/8 in
Manufacturer Warranty Length
1 yr Limited
Outlet Width
5 3/4 in
Inlet Diameter
8 in
Wheel Width
4 3/8 in

Details

Item
High Pressure Blower
Type
With Motor
Voltage
208-230/460
Motor HP
5 hp
Housing Material
Steel
CFM @ 4.000-In. SP
1777
CFM @ 0.500-In. SP
2079
Hz
60/50
Phase
3
Blower RPM
3,500 RPM
CFM @ 8.000-In. SP
1367
Motor RPM
3,500 RPM
Bearing Type
Ball
CFM @ 7.000-In. SP
1482
CFM @ 3.000-In. SP
1866
CFM @ 5.000-In. SP
1685
dBA @ 5 Feet
92 dBA
CFM @ 2.000-In. SP
1952
Max. Inlet Temp. (Deg. F)
180 Degrees F
CFM @ 0.250-In. SP
2100
Full Load Amps
13.5-12.2/6.1
CFM @ 1.500-In. SP
1995
Housing Finish
Gray Polyester Epoxy
Assembled/Unassembled
Assembled
Motor Frame
184T
Rotation
CW
Max. Ambient Temp. (F)
104 Degrees F
CFM @ 1.000-In. SP
2037
CFM @ 6.000-In. SP
1587
Wheel Bore (In.)
1 1/8 in
Wheel Material
Aluminum
Agency Compliance
CE, CSA, UL
Motor Enclosure
Totally Enclosed Fan Cooled
Maximum Static Pressure
12 in wc
Includes Motor
Yes
Standards
Not Rated
Drive Type
Direct Drive
Features
Self-Cleaning Cast Aluminum Wheels
Includes Drive Package
Yes
Motor Horsepower
5 hp
Maximum Inlet Air Temperature
180 Degrees F
Airflow @ 7.000 in SP
1,482 cfm
Sound Level
92 dBA @ 5 ft
Frequency
60 Hz
Airflow @ 5.000 in SP
1,685 cfm
Number of Discharge Positions
8
Maximum Ambient Temperature
104 Degrees F
Discharge Position
Bottom Angular Down, Bottom Angular Up, Bottom Horizontal, Down Blast, Top Angular Down, Top Angular Up, Top Horizontal, Up Blast
Assembly
Assembled
Wheel Type
Radial
Airflow @ 0.250 in SP
2,100 cfm
Flange Type
Non-Flanged
Airflow @ 2.000 in SP
1,952 cfm
Airflow @ 1.500 in SP
1,995 cfm
Airflow @ 0.500 in SP
2,079 cfm
Airflow @ 3.000 in SP
1,866 cfm
Airflow @ 1.000 in SP
2,037 cfm
Number of Inlets
1
For Air Type
Dirty and Dusty
Maximum Fan Speed
3,500 RPM
Application
Fibrous Material Such as Textile Scrap, Wool and Ensilage, Long Stringy Material, Paper Trim
Housing Material Finish
Baked Enamel
Outlet Shape
Rectangular
Nameplate Voltage
230/460
For Ventilation Type
Exhaust
Airflow @ 8.000 in SP
1,367 cfm
Motor Frame Designation
184T
Current
11.6/5.8
Housing Color
Gray
Motor Speed
3,500 RPM
Airflow @ 4.000 in SP
1,777 cfm
Mount Type
Motor Mount
Airflow @ 6.000 in SP
1,587 cfm
OEM Replacement
No
Chemical Resistant
No
Spark Resistant Construction Type
Not Rated
Motor Duty Class
Continuous
AMCA Fan Class
Not Rated
Hazardous Location Specification
N
For High-Static Pressure Applications
Yes
Hazardous Location Application
No
Motor Location
Out of Airstream
Number of Speeds
1
Speed Controllable
No
Corrosion Resistant
Yes

Description

High Pressure Blower, Wheel Type Radial, Drive Type Direct Drive, Includes Drive Package Yes, Assembly Assembled, Wheel Diameter 13 1/2 in, Airflow @ 0.250 in SP 2,100 cfm, Airflow @ 0.500 in SP 2,079 cfm, Airflow @ 1.000 in SP 2,037 cfm, Airflow @ 1.500 in SP 1,995 cfm, Airflow @ 2.000 in SP 1,952 cfm, Airflow @ 3.000 in SP 1,866 cfm, Airflow @ 4.000 in SP 1,777 cfm, Airflow @ 5.000 in SP 1,685 cfm, Airflow @ 6.000 in SP 1,587 cfm, Airflow @ 7.000 in SP 1,482 cfm
