Dayton

Louver, Intake, 12-18 In, Aluminum

product price: $118.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Louver Type Stationary Blade
  • Louver Free Area 0.360 to 0.550 sq ft
  • For Use With Intake or Exhaust Applications
  • Min. Wall Opening (In.) 14H x 12W
  • Louver Max. Intake 616 cfm
See all product information

Product Information

Dimensions

Intake Louver Inside Width 12 in to 18 in
Intake Louver Outside Height 18 in
Flange Width (In.) 2 in
Outside Width (In.) 16 to 22
Inside Height (In.) 14 in
Mounting Hole Size (In.) 9/32 x 1/2
Minimum Outside Width 16 in
Inside Width 12 in
Rough Opening Height 14 in
Fixed or Adjustable Dimensions Adjustable Width
Inside Height 14 in
Maximum Outside Width 22 in
Outside Height 18 in
Rough Opening Width 12 in
Flange Width 2 in
Outside Width 16 in
Frame Depth 4 in

Details

Item 18"H 16"W Non-Drnbl Alu Intake Louver
Louver Item Stationary Intake Louver
Louver Type Stationary Blade
Louver Free Area 0.360 to 0.550 sq ft
For Use With Intake or Exhaust Applications
Min. Wall Opening (In.) 14H x 12W
Louver Max. Intake 616 cfm
Louver Max. Exhaust 875 cfm
Louver Material 3003 Aluminum
Includes Bird Screen, Screen Fasteners
Number of Blades 1
Max. Velocity (FPM) 3,000 fpm
Blade Angle (Deg.) 45
Blade Angle 45 Degrees
Intake or Exhaust Application Exhaust, Intake
Blade Type Non-Drainable
Maximum Exhaust 875 cfm
Louver Maximum Intake 616 cfm
Finish Mill
Material Grade 3003
Maximum Air Velocity 3000 fpm
Material Aluminum
Frame Type Flanged
Free Area 0.6 sq ft
Mounting Style Surface Mount
Beginning Point of Water Penetration 766 fpm

Description

18 In.H 16 In.W Non-Drnbl Alu Intake Louver, Louver Type Stationary Blade, Frame Type Flanged, Frame Depth 4 in, Mounting Style Surface Mount, Outside Height 18 in, Outside Width 16 in, Rough Opening Height 14 in, Rough Opening Width 12 in, Louver Maximum Intake 616 cfm, Maximum Exhaust 875 cfm, Maximum Outside Width 22 in, Minimum Outside Width 16 in, Flange Width 2 in, Free Area 0.6 sq ft, Beginning Point of Water Penetration 766 fpm, Maximum Air Velocity 3000 fpm, Blade Angle 45 Degrees
