Dayton
Speed Reducer, C-Face, 56C, 29:1
- Zoro #: G0789004
- Mfr #: 2Z934
Tap to zoom
Hover or click to zoom
This item ships free.
(Sign in or create an account for free shipping on orders over $50)
Total: $726.22
Dayton #2Z934 Specifications
- Zoro #: G0789004
- Mfr #: 2Z934
- Item: Speed Reducer
- Nominal Ratio: 29:1
- Input RPM: 1750 rpm
- Bore Dia.: 5/8"
- Nominal Output RPM: 60
- Standards: AGMA
- Max. Input HP: 0.5 hp
- Output Torque @ 1/3 HP: 318 in-lb
- Output Torque @ 1/4 HP: 235 in-lb
- Seal Type: Double Lip
- Dimension U: 1 in
- Output Torque @ 3/4 HP: 478 in.-lb.
- Lubrication: Klubersynth UH1 6-460
- Speed Reducer Type: C-Face
- Solid/Hollow Output Shaft: Solid
- Reducer Model No.: 84380
- Overhung Load: 660 lb
- Mounting: Horizontal
- Bearings: Ball
- Shaft Orientation: Parallel/Inline
- Finish: Powdered Epoxy Paint
- Single/Double Output/Universal: Single Output
- Frame: 56c
- Number of Stages: 1
- Output Torque @ 1/40 HP: 3600 in.-lb.
- Output Torque @ 1/2 HP: 478 in-lb
- Output Shaft Height: 4 7/8 in
- Housing Material: Cast iron
- Max. Output Torque: 478 in-lb
- Pinion Material: Hardened Steel
- Duty: Standard
- Rotation: Forward/Reversible
- Gear Type: Helical
- Gear Material: Hardened and Ground Steel
- Output Shaft Dia.: 1 in
- Nominal Output rpm: 60 rpm
- Country of Origin (subject to change): United States
Description
The Dayton C-Face Gear Reducer is a high performance gearbox that is designed to handle a wide range of material handling applications. The gearbox features a cast iron housing for maximum strength and durability. The gearbox is also built-in with a steel shaft for maximum strength. The C-Face design of the unit allows for a compact space-saving design. It can be used horizontally, and is designed to handle a wide range of applications.
Restrictions and Compliance
- WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
