12V MAX* Compatible 5 Spot + Cross Line Red Laser (Discontinued)

The DEWALT DW0825LR 12V MAX* Compatible 5 Spot + Cross Line Red Laser is a self-leveling laser tool rated for use in layout and alignment tasks in indoor and outdoor environments. It projects five spot beams along with horizontal and vertical cross lines, suitable for a range of applications. The unit features an IP65 rating for debris and water resistance, as well as a 2-meter drop protection rating to withstand tough job site conditions.

Key Features of the DEWALT DW0825LR 5 Spot + Cross Line Red Laser:

• Spot and Cross Line Capability: Projects five spots (up/down/front/left/right) plus horizontal and vertical cross lines for multiple layout options.


• Accuracy: Rated at +/-1/8 in at 30 ft, suitable for precise alignment work.


• Self-Leveling Range: Provides electronic self-leveling within +/-5 degrees that simplifies setup on uneven surfaces.


• Range: Up to 165 ft working range with detector; up to 100 ft without detector support.


• Power Source Compatibility: Operates on either AA batteries or a compatible DEWALT 12V Li-Ion battery pack (batteries included).


• Mounting Options: Integrated magnetic bracket, pivoting thread mount, and supports multiple mounting options allowing flexible placement.


• Toughness Ratings: IP65 rated against dust/water ingress; tested under specified drop protection rating (2 meters).


• Pendulum Lock & Indicators: Includes locking pendulum mechanism plus visual/audible level indicators for added convenience during use.
