Dormakaba Electronic Locks, 5000, Antique Brass E5710XSWL-744-41 - main

Electronic Locks, 5000, Antique Brass

  • Mfr # E5710XSWL-744-41

  • Zoro # G1616706

product price: $1,531.99
/ea
Free Shipping & Returns

Key Features

Handle Type
Lever
Function
Storeroom
Key Override Options
Schlage C Keyway
Hand
Nonhanded
Finish
Antique Brass
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
E5710XSWL-744-41
Zoro #
G1616706
UPC #
-
Country of Origin
United States

Dimensions

Door Thickness
1-3/4 in
Latch Length
1/2 in
Outside Width
4 1/4 in
Latch Front Size
1-1/8 in X 2 in
Inside Height
8 7/8 in
Outside Height
8 7/8 in
Inside Depth
1 3/8 in
Inside Width
3 3/16 in
Overall Width
4 1/4 in
Overall Height
8 7/8 in
Door Thickness - Maximum
1 3/4 in
Latch Front Length
2 in
Latch Front Width
1 1/8 in

Details

Item
Electronic Keyless Lock
Handle Type
Lever
Function
Storeroom
Key Override Options
Schlage C Keyway
Hand
Nonhanded
Finish
Antique Brass
Backset
2 3/4 in
Electrical/Mechanical
Electrical
Product Type
Electronic Keyless Lock
Lockset Function
Storeroom
Case Material
Bronze
Grade
1
Weather Resistant
Yes
Max. User Codes
3000
Series
5000
Operating Temp. Range
-31 Degrees to 130 Degrees F
Power Source
(4) AA Batteries
Keypad Material
Metal
Timed Entry Allowance
1 to 99 sec
Fire Rating
Yes
ADA Compliant
Yes
Standards
UL Listed
Battery Life
1 yr
For Use With
Commercial Doors
Max. Proximity Range
At Lock
Lock Material
Metal
Event Audit Trail
9000
Number of Keys
2
Mounting Style
Exit Trim
Access Method
Keypad and Proximity Card
Network Interface
AL-DTM2
User Codes - Maximum
3,000
Lockset Type
Electrical
Lockset Handle Type
Lever
Lockset Material
Metal
Cylinder Core Type
Conventional Core Cylinder
Temperature - Minimum
-31 Degrees F
Temperature - Maximum
130 Degrees F
Hand Orientation
Non-Handed
ANSI/BHMA Finish
Dark Oxidized Satin Bronze, Oil Rubbed
Event Audit Trails
9,000

Description

Electronic Keyless Lock, Function Storeroom, Access Method Keypad and Proximity Card, Mounting Style Exit Trim, Lock Material Metal, Finish Antique Brass, Series 5000, Handle Type Lever, Door Thickness 1-3/4 in, Key Override Options Schlage C Keyway, Hand Nonhanded, Network Interface AL-DTM2, Outside Height 8 7/8 in, Outside Width 4 1/4 in, Keypad Material Metal, Power Source (4) AA Batteries, Battery Life 1 yr, Operating Temp. Range -31 Degrees to 130 Degrees F, Max. User Codes 3000
