  13. Lever Lockset, Mechanical, Passage, Grd. 2
Dormakaba Lever Lockset, Mechanical, Passage, Grd. 2 QCI230E613NS4118FSCKD - main

Lever Lockset, Mechanical, Passage, Grd. 2

  • Mfr # QCI230E613NS4118FSCKD

  • Zoro # G1605987

product price: $269.99
/ea
Free Shipping & Returns

Key Features

Electrical/Mechanical
Mechanical
Lockset Handle Type
Lever
Mortise / Cylindrical
Cylindrical
Lockset Function
Passage
Lockset Grade
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
QCI230E613NS4118FSCKD
Zoro #
G1605987
UPC #
-
Country of Origin
Taiwan, Province of China

Dimensions

Required Door Thickness
2-3/4 in
Door Thickness - Minimum
1 3/8 in
Strike Plate Height
2 3/4 in
Strike Plate Width
1 1/8 in
Door Thickness - Maximum
1 3/4 in

Details

Electrical/Mechanical
Mechanical
Lockset Handle Type
Lever
Mortise / Cylindrical
Cylindrical
Lockset Function
Passage
Lockset Grade
2
Style
QCI230 Sierra
Lockset Finish
Oil Rubbed Bronze
Keyway Type
Schlage C
Key Type
Keyed Different
Location Type
Apartment Complex, Government Facility, Hotel, Multi-Family, Office Building, Religious, Retail
Handle Material
Zinc
Standards
ANSI A117.1, ANSI/BHMA A156.12, UL and cUL Listed
For Use With
various Door Types
Strike Dim.
1-1/8 in x 2-1/4 in
Backset
2 3/4 in
Ligature Resistant
No
Lockset Performance Strength
Standard Duty
Key Material
Nickel Silver
Number of Pins
6
Item
Door Lockset
Lockset Fire Rating
3 hr
Features
Interconnected Locks
Strike Type
Deadbolt, T-Strike
ADA Compliant
Yes
Includes
Hardware
Number of Keys
2
Cylinder Core Type
Cylinder with Schlage "C" Keyway
Series
QCI230
Finish
Oil Rubbed Bronze
Fire Rated
Yes
Grade
2
Keying
Keyed Different
Visual Indicator Message
No Message
Mortise/Cylindrical
Cylindrical
Hand Orientation
Non-Handed
Lockset Type
Mechanical
Lockset Style
QCI Sierra
Knob/Handle Material
Bronze
ANSI/BHMA Finish
Dark Oxidized Satin Bronze, Oil Rubbed
Fire Rating
3 hr
Ligature-Resistant
Not Ligature-Resistant
Includes Hardware
Hardware Included
Latch Bolt/Dead Bolt
Dead Bolt, Spring Latch
ANSI Grade
2
Application
Multiple Family Residential, Commercial
Performance Grade
2
Lockset Function ANSI Code
F95
Locking/Unlocking Access - Outside
Not Lockable
Locking/Unlocking Access - Inside
Not Lockable
UL Fire Rating
UL10C

Description

Lever Lockset,Mechanical,Passage,Grd. 2
