Shop DOTCO

In-Line Die Grinder, 1/4 in NPT Female Air Inlet, 1/4 in Collet, Heavy Duty, 20,000 RPM, 0.4 hp

  • Mfr # 12LF201-36

  • Zoro # G4534433

product price:
$
615.99
/ea
Free Shipping & Returns

Key Features

Overall Length
6 5/8 in
Air Inlet
1/4 in NPT Female
Horsepower
0.4 hp
Free Speed
20,000 RPM
Max. Speed
20,000 RPM
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
12LF201-36
Zoro #
G4534433
UPC #
-
Country of Origin
United States

Dimensions

Overall Length
6 5/8 in
Min. Hose Size
1/4 in
Right Angle Length
2 3/4 in
Air Inlet Connection Size
1/4 in
Maximum Burr Diameter
1/4 in
For Wheel Dia.
1/2 in
Collet Size
1/4 in
Head Height
2.70 in
Hose Size - Minimum
1/4 in
Burr Diameter - Maximum
1/4 in
For Wheel Diameter
1/2 in
Wire Rope Length
6 5/8 in
Length
6 5/8 in

Details

Item
Die Grinder
Air Inlet
1/4 in NPT Female
Horsepower
0.4 hp
Free Speed
20,000 RPM
Max. Speed
20,000 RPM
Grinder Type
Right Angle
Includes
Collet Wrenches
CFM @ Full Load
9.0
Collet
1/4 in
Average CFM @ 15 Second Run Time
2.25
Housing Material
Composite
Variable Speed
No
Bearing Type
Double Shielded Ball
Handle Material
Composite
Characteristics
300 Series Collet
Duty
Heavy Duty
Grinder Orientation
Right Angle
Throttle
Lever
Tool Weight
1.1 lb
Features
Ergonomic and Balanced Design To Minimize Operator Fatigue
Application
Pipe Fabricating, Shipbuilding, Transportation Equipment Manufacturing, Welding Applications
Air Inlet Type
NPT
Air Consumption
9 cfm
Minimum Speed
20,000 RPM
Series
12LF Series
Anti-Vibration Technology
Yes
Tether Style
Not Tether Capable
Tool Style
Right Angle
Exhaust Location
Front
Switch Type
Lever
Air Pressure
90 psi
Power Source
Air Powered
Accessory Free Tool Change
No
Kit Contents
(1) Bare Tool
Air Inlet Gender
Female
Anti-Kickback Clutch Type
None
Speed - Maximum
20,000 RPM
Tool Series
12LF
Frequency of Use
Frequent Maintenance to Heavy Production
Speed - Minimum
20,000 RPM
Tool Life
Long Lasting
Robot Mounting Components Included
Tool Only
Power Source - TS Only
Air Powered
Power Source - old
Air Powered

Description

Die Grinder, Duty Heavy Duty, Horsepower 0.4 hp, Collet Size 1/4 in, Grinder Orientation Right Angle, Air Inlet Connection Size 1/4 in, Air Inlet Gender Female, Max. Speed 20,000 RPM, Air Inlet Type NPT, Air Inlet 1/4 in NPT Female, Tool Style Right Angle, Kit Contents (1) Bare Tool, Includes Collet Wrenches, Anti-Kickback Clutch Type None, Power Source Air Powered
