Digital Panel Meter, LCD Display
- Mfr # DPMA-402
- Zoro # G307146484
product price:Â
$
229.99
/ea
Free Shipping & Returns
Key Features
Length
5.7 in
Width
2.3 in
Height
2.3 in
Weight
0.3 lbs
Series
DPMA
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- DPMA-402
- Zoro #
- G307146484
- UPC #
- -
- Country of Origin
- Macao
- Weight
- 0.3 lbs
- Series
- DPMA
- Display Features
- High Contrast
- Accuracy
- +/-0.05%
- Digital Display Screen Type
- LCD
- Display Span - Maximum
- 1,999
- Product Type
- LCD Digital Panel Meter
- DC Voltage Input - Maximum
- 24 V DC
- DC Voltage Input - Minimum
- 15 V DC
- Number of Display Digits
- 3.5
- Terminal Connection Type
- Screw Clamp
- Standards
- RoHS
- Current Display - Minimum
- 4 mA
- Parameters Measured
- AC Current, DC Current, DC Voltage
- Digital Display Screen Color
- Red
- NEMA Enclosure Rating
- 4
- Item
- Digital Panel Meter
- Includes Mounting Hardware
- Included
- Current Display - Maximum
- 20 mA
Dimensions
- Length
- 5.7 in
- Width
- 2.3 in
- Height
- 2.3 in
- Cutout Height
- 1 49/64 in
- Cutout Width
- 3 5/8 in
- Overall Width
- 2.3 in
- Cutout DIN Size
- 8-Jan
- Overall Height
- 2.3 in
- Digit Height - Minimum
- 0.45 in
- Digit Height - Maximum
- 1 in
- Overall Depth
- 5.7 in
Description
Digital Panel Meter, Current; Humidity; Pressure; Temperature; Voltage; Watt/Power Factor Transmitter, Input Range 4 to 20 mA, Accuracy +/-0.05 Percent, Display Span +/-1,999, Display Digits 3 1/2, LCD Display, Fits 3.62 in x 1.77 in Cut Out, Connector Type Screw Terminal, Not Applicable Interface, Mounting Clamp, Panel, Style DPMA
