Shop DWYER INSTRUMENTS

Digital Temperature Controller, 90.09mm L

  • Mfr # SCD-1033
  • Zoro # G210070388
product price:
$
161.99
/ea
Free Shipping & Returns

Key Features

Digital/Analog
Digital
Sensor Type
B, E, J, K, L, N, Platinum RTD, R, S, T, Thermocouple, TXK, U
Description/Special Features
Dual Loop or Single Loop/Alarm Output Control, RS-485 Modbus(R) Communication, Universal Transmitter or Temperature Sensor Inputs
Voltage
24V DC
Input Voltage
24V DC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
SCD-1033
Zoro #
G210070388
UPC #
-
Country of Origin
China
Item
Temperature Controller
Digital/Analog
Digital
Sensor Type
B, E, J, K, L, N, Platinum RTD, R, S, T, Thermocouple, TXK, U
Description/Special Features
Dual Loop or Single Loop/Alarm Output Control, RS-485 Modbus(R) Communication, Universal Transmitter or Temperature Sensor Inputs
Voltage
24V DC
Input Voltage
24V DC
Switch Function
3 A @ 250V AC Resistive
Output
(2) Relay
Temp. Range
32 Degrees to 122 Degrees F
Control Mode
PID
Amps
3A
Series
SCD
Power Consumption
3 W
Standards
CE, cULus, RoHS
Memory Backup
Non-volatile.
Operating Temperature
32 to 122ºF (0 to 50ºC).
Inputs
Thermocouple, RTD, DC linear voltage, and DC currents.
Control Output Ratings
Relay: 3 A @ 250 VAC resistive; Voltage pulse: 12 VDC, max. output current: 40 mA; Current: 4 to 20 mA output; Linear voltage: 0 to 10 VDC.
Agency Approvals
CE, cULus.
Communication
RS-485 Modbus® A-5-11/RTU communication protocol.
Current
20 mA
Temperature - Maximum
122 Degrees F
Display Type
Digital
Temperature - Minimum
32 Degrees F
Product Type
Temperature Controller
Fahrenheit Temperature - Minimum
32 Degrees F
Operating Environment
Indoor
Celsius Temperature - Minimum
-999 Degrees C
Celsius Temperature - Maximum
9,999 Degrees C
Controller Options
SPDT
Fahrenheit Temperature - Maximum
122 Degrees F
Parameters Measured
Temperature Degrees C, Temperature Degrees F

Description

Temperature Controller, Digital, B, E, J, K, L, N, Platinum RTD, R, S, T, Thermocouple, TXK, U Sensor Type, DIN Size Not Applicable, Input Voltage 24V DC, Switch Function 3 A @ 250V AC Resistive, Output (2) Relay, Temp. Range 32 Degrees to 122 Degrees F, Control Mode PID, 3A Amps, Length 90.09 mm, Width 25.4 mm, Depth 57.15 mm, Dual Loop or Single Loop/Alarm Output Control, RS-485 Modbus(R) Communication, Universal Transmitter or Temperature Sensor Inputs, Power Consumption 3 W
