  13. European wall mount temperature transmitter with 4 to 20 mA output
Dwyer Instruments European wall mount temperature transmitter with 4 to 20 mA output BTT-E00-3 - main

European wall mount temperature transmitter with 4 to 20 mA output

  • Mfr # BTT-E00-3

  • Zoro # G407148999

product price: $73.65
/ea

Key Features

Accuracy
±0.5°C @ 25°C.
Process Connection
1/2" NPT (immersion models only).
Wetted Materials
All models: 304 SS (probe), polycarbonate (housing); Duct and immersion models: Neoprene (gasket); Outside air models: Nylon (insert), silicone (O-ring).
Temperature Limits
Operating: -40 to 302°F (-40 to 150°C).
Output Signal
4 to 20 mA or 0 to 10 VDC (depending on model).
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
BTT-E00-3
Zoro #
G407148999
UPC #
-
Country of Origin
China

Details

Accuracy
±0.5°C @ 25°C.
Process Connection
1/2" NPT (immersion models only).
Wetted Materials
All models: 304 SS (probe), polycarbonate (housing); Duct and immersion models: Neoprene (gasket); Outside air models: Nylon (insert), silicone (O-ring).
Temperature Limits
Operating: -40 to 302°F (-40 to 150°C).
Output Signal
4 to 20 mA or 0 to 10 VDC (depending on model).
Enclosure Rating
NEMA 4X (IP66) (immersions models require thermowell).
Response Time
100 ms.
Features
Duct, immersion, and outside air models available; Radiation shield available for mounting in direct sunlight; Transmitter output allows for longer wire runs than standard thermistor sensors
Agency Approvals
CE.
Power Requirements
13 to 36 VDC for current models, 13 to 36 VDC or 16 to 28 VAC for voltage models.
Conduit Connection
1/2" NPT.
Thermal Effect
±0.01%/°C.

Description

European wall mount temperature transmitter with 4 to 20 mA output
