Flowmeter, range .1-1 SCFH air, no valve.
Mfr # RMA-2
Zoro # G1438827
product price:Â
$
67.89
/ea
Key Features
Accuracy
4%
Housing Material
Polycarbonate
Overall Height
4.8 in
Overall Width
1 in
Standards
EU Directive 2011/65/EU, RoHS II Compliant
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- RMA-2
- Zoro #
- G1438827
- UPC #
- -
- Country of Origin
- Taiwan, Province of China
Dimensions
- Overall Height
- 4.8 in
- Overall Width
- 1 in
- Overall Length
- 2.6 in
- For Pipe Size
- 1/8 in
- Connection Size
- 1/8 in
- Wire Rope Length
- 2.6 in
- Length
- 2.6 in
Details
- Item
- Flowmeter
- Accuracy
- 4%
- Housing Material
- Polycarbonate
- Standards
- EU Directive 2011/65/EU, RoHS II Compliant
- Unit Of Measure
- Gallons, Liters
- Product Type
- Variable Area Flowmeter
- O-Ring Material
- Buna-N, Neoprene
- Includes Flow Rate Adjustment Knob
- Yes
- Flowmeter Type
- Variable Area
- Flow Rate - Maximum
- 1 scfh
- Mounting Orientation
- Vertical
- Media Temperature - Maximum
- 130 Degrees F
- Connection Type
- FNPT
- Wetted Material
- Aluminum, Buna-N, Glass, K500 Nickel-Copper Alloy, Neoprene, Polycarbonate, Stainless Steel, Tungsten Carbide
- Flow Rate - Minimum
- 0.1 scfh
- Compatible Flow Material
- Air
- Operating Pressure - Maximum
- 100 psi
Description
Flowmeter, Product Type Variable Area Flowmeter, Flowmeter Type Variable Area, Accuracy 4 Percent, Connection Size 1/8 in, Connection Type FNPT, Compatible Flow Material Air, Media Temperature - Maximum 130 Degrees F, Media Temperature - Minimum Not Applicable, Viscosity - Maximum Not Applicable, Voltage - Maximum Not Applicable, Housing Material Polycarbonate, Rotor Material Not Applicable, O-Ring Material Buna-N, Neoprene, Seal Material Not Applicable, Shaft Material Not Applicable
