Dwyer Instruments Galvanic Barrier, Repeater Power Supply MTL5541 - main

Galvanic Barrier, Repeater Power Supply

  • Mfr # MTL5541

  • Zoro # G607149079

product price: $1,239.99
/ea
Free Shipping & Returns

Key Features

Features
Meet application requirements with durable cage design with large diameter 316 SS diaphragm seal that is non-clogging and damage resistant to floating solids; Increased life with lightning and surge protection utilizing dual arrestor technology, grounded to case, eliminating both power supply surges and lightning ground strike transients (surge protection is not guaranteed and is not covered by warranty) on PBLT2 models; Eliminates particulate or water droplets from entering the transducer using maintenance-free filter; Peace of mind with UL approved intrinsically safe on PBLTX models for use in hazardous locations when used with proper barrier; Decrease ownership cost with durable, 270 lb tensile strength shielded and vented cable and excellent chemical compatibility; Flexible installation options with NPT connection to rigidly install in a pipe/conduit or use a A-625 hanging loop to attach a chain to remove from the installation
Wetted Materials
Body: 316 SS, 316L SS; Cable: Polyether polyurethane or ETFE; Seals: Fluoroelastomer.
Accuracy
±0.25% FS (includes linearity, hysteresis, and repeatability).
Response Time
50 msec.
Pressure Limit
2X FS.
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
MTL5541
Zoro #
G607149079
UPC #
-
Country of Origin
India

Details

Item
Galvanic Barrier
Features
Meet application requirements with durable cage design with large diameter 316 SS diaphragm seal that is non-clogging and damage resistant to floating solids; Increased life with lightning and surge protection utilizing dual arrestor technology, grounded to case, eliminating both power supply surges and lightning ground strike transients (surge protection is not guaranteed and is not covered by warranty) on PBLT2 models; Eliminates particulate or water droplets from entering the transducer using maintenance-free filter; Peace of mind with UL approved intrinsically safe on PBLTX models for use in hazardous locations when used with proper barrier; Decrease ownership cost with durable, 270 lb tensile strength shielded and vented cable and excellent chemical compatibility; Flexible installation options with NPT connection to rigidly install in a pipe/conduit or use a A-625 hanging loop to attach a chain to remove from the installation
Wetted Materials
Body: 316 SS, 316L SS; Cable: Polyether polyurethane or ETFE; Seals: Fluoroelastomer.
Accuracy
±0.25% FS (includes linearity, hysteresis, and repeatability).
Response Time
50 msec.
Pressure Limit
2X FS.
Thermal Effect
±0.02% FS/°F.
Output Signal
4 to 20 mA DC, two wire.
Agency Approvals
PBLT2: CE, PBLTX: CE, cULus intrinsically safe for Class I, Div. 1, Groups A, B, C, D; Class II, Div. 1, Groups E, F, G; Class III, Div. 1; ATEX: II 1 G Ex ia IIC T4 Ga and II 1 D Ex ia IIIC T135C Da (According to control drawing 001833-44)**.
Loop Resistance
900 Ω.
Mounting Orientation
Suspended in tank below level being measured.
Service
Compatible liquids.
Temperature Limit
PBLT2: 0 to 200°F (-18 to 93°C); PBLTX: ETFE -4 to 176°F (-20 to 80°C); Polyurethane: -4 to 149°F (-20 to 65°C)
Enclosure Rating
IP68; 20 m for 24 hrs per IEC 60529.

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
