  13. North American wall mount temperature transmitter with 0 to 10 VDC output
Dwyer Instruments North American wall mount temperature transmitter with 0 to 10 VDC output BTT-N00-4 - main

North American wall mount temperature transmitter with 0 to 10 VDC output

  • Mfr # BTT-N00-4

  • Zoro # G707149047

product price: $82.15
/ea
Free Shipping & Returns

Key Features

Accuracy
±0.5°C @ 25°C.
Process Connection
1/2" NPT (immersion models only).
Features
Duct, immersion, and outside air models available; Radiation shield available for mounting in direct sunlight; Transmitter output allows for longer wire runs than standard thermistor sensors
Power Requirements
13 to 36 VDC for current models, 13 to 36 VDC or 16 to 28 VAC for voltage models.
Wetted Materials
All models: 304 SS (probe), polycarbonate (housing); Duct and immersion models: Neoprene (gasket); Outside air models: Nylon (insert), silicone (O-ring).
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
BTT-N00-4
Zoro #
G707149047
UPC #
-
Country of Origin
China

Details

Accuracy
±0.5°C @ 25°C.
Process Connection
1/2" NPT (immersion models only).
Features
Duct, immersion, and outside air models available; Radiation shield available for mounting in direct sunlight; Transmitter output allows for longer wire runs than standard thermistor sensors
Power Requirements
13 to 36 VDC for current models, 13 to 36 VDC or 16 to 28 VAC for voltage models.
Wetted Materials
All models: 304 SS (probe), polycarbonate (housing); Duct and immersion models: Neoprene (gasket); Outside air models: Nylon (insert), silicone (O-ring).
Enclosure Rating
NEMA 4X (IP66) (immersions models require thermowell).
Output Signal
4 to 20 mA or 0 to 10 VDC (depending on model).
Thermal Effect
±0.01%/°C.
Temperature Limits
Operating: -40 to 302°F (-40 to 150°C).
Response Time
100 ms.
Agency Approvals
CE.
Conduit Connection
1/2" NPT.

Description

North American wall mount temperature transmitter with 0 to 10 VDC output
