Pressure Switch, SPDT, 1/8" NPT, 0 to 15 in H2O Range
Mfr # 3015MR
Zoro # G807143372
product price:Â
$
663.75
/ea
Free Shipping & Returns
Key Features
Contact Form
SPDT
Pressure Connection Type
1/8 in FNPT
Range
0-15" w.c.
Standards
CE
Accuracy
±2% of FS (3000-0 ±3% of FS). (3000-00 ±4% of FS).
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 3015MR
- Zoro #
- G807143372
- UPC #
- -
- Country of Origin
- United States
- Item
- Pressure Switch
- Contact Form
- SPDT
- Pressure Connection Type
- 1/8 in FNPT
- Range
- 0-15" w.c.
- Standards
- CE
- Accuracy
- ±2% of FS (3000-0 ±3% of FS). (3000-00 ±4% of FS).
- Features
- Gage reading unaffected by switch operation and will continue to read pressure even during power loss; Zero and range adjustments outside of gage means no disassembly in normal service; Solid-state design allows for switching in high cycle rate applications without degradation
- Process Connections
- 1/8" female NPT (duplicated side and back).
- Switching Voltage
- 20-280 VAC (47-63 Hz).
- Agency Approvals
- CE.
- Relay Contacts
- (Resistive load) 1 form C rated 1.0A @ 30 VDC, 0.3A @ 110 VDC or 0.5A @ 125 VAC. Gold over clad silver - suitable for dry circuits.
- Switching Current
- 1.0 amp (AC) max., 0.01 mA (AC) min., (2) SPST NO.
- Power Requirements
- 24 VDC, regulated ±10%.
- Switch Type
- Each setpoint has 1 form C relays (SPDT).
- Pressure Limit
- -20" Hg. to 25 psig (-0.677 bar to 1.72 bar). MP option: 35 psig (2.41 bar), HP option: 80 psig (5.52 bar).
- Service
- Air and non-combustible, compatible gases.
- Set Point Adjustment
- Adjustable knobs on face.
- Mounting Orientation
- Diaphragm in vertical position. Consult factory for other position orientations.
- Temperature Limits
- 20 to 120°F (-6.67 to 48.9°C).
Description
Pressure switch/gage, range 0-15" w.c., .50 minor divisions.
