  9. Pressure switch/gage, range 0-10" w.c., .20 minor divisions.
Dwyer Instruments Pressure switch/gage, range 0-10" w.c., .20 minor divisions. 3010MR - main

Pressure switch/gage, range 0-10" w.c., .20 minor divisions.

  • Mfr # 3010MR

  • Zoro # G1439061

product price: $624.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-2%
Process Connection Type
NPT
Process Connection Size
1/8 in
Series
3000MR
Process Connection Gender
Female
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
3010MR
Zoro #
G1439061
UPC #
-
Country of Origin
United States

Dimensions

Process Connection Size
1/8 in
Nominal Dial Size
4 in
Bolt Circle Diameter
5.125 in
Case Diameter
5 in
Case Depth
2.5 in

Details

Item
Pressure Switch/Gauge
Accuracy
+/-2%
Process Connection Type
NPT
Series
3000MR
Process Connection Gender
Female
Application
Air Conditioning Systems, Clean Rooms, Pneumatic Conveying
Process Connection Location
Back, Side
Pressure Range
0 to 10 in wc
Sensor Type
Diaphragm
Relay Type
SPDT
Standards
CE
Ambient Operating Temperature Range
20 Degrees to 120 Degrees F
Case Shape
Round
Pressure Gauge Type
Differential Pressure Gauge with Switch
Switch Contact Type
SPDT
Compatible Process Media
Air, Non-Combustible Compatible Gases
Panel-Mountable
Yes
Switch Electrical Requirements
0.3A @ 110V DC/0.5A @ 125V AC; 1A @ 30V DC
Panel Mount Characteristics
(4) 6-32 Holes Equally Spaced on a 5-1/8 in Dia Bolt Circle
Mounting Orientation
Upright Only
Accuracy Details
+/-2% FS
Maximum Working Static Pressure
25 psig
Includes Mounting Hardware
Yes
Power Source
24V DC
Includes Calibration Certificate
No
Adjustable Set Points
Yes
Pressure Measurement - Minimum
0 in wc
Operating Temperature - Maximum
120 Degrees F
Pressure Measurement - Maximum
10 in wc
Operating Temperature - Minimum
20 Degrees F
Switch Contact Form
SPDT
Working Static Pressure - Maximum
25 psig

Description

Pressure Switch/Gage Range 0-10 Wc 20
