Pressure switch/gage, range 0-50 mm w.c., 1.0 minor divisions.
- Mfr # 3000MRS-50MM
- Zoro # G610474731
product price:Â
$
789.99
/ea
Free Shipping & Returns
Key Features
Pressure Connection Type
1/8 in FNPT
Range
0-50 mm w.c.
Standards
CE
Features
Gage reading unaffected by switch operation and will continue to read pressure even during power loss; Zero and range adjustments outside of gage means no disassembly in normal service; Solid-state design allows for switching in high cycle rate applications without degradation
Accuracy
±2% of FS (3000-0 ±3% of FS). (3000-00 ±4% of FS).
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 3000MRS-50MM
- Zoro #
- G610474731
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Size
- 4" (101.6 mm) dial face, 5" (127 mm) OD x 3-1/8" (79.38 mm).
Details
- Item
- Pressure Switch
- Pressure Connection Type
- 1/8 in FNPT
- Range
- 0-50 mm w.c.
- Standards
- CE
- Features
- Gage reading unaffected by switch operation and will continue to read pressure even during power loss; Zero and range adjustments outside of gage means no disassembly in normal service; Solid-state design allows for switching in high cycle rate applications without degradation
- Accuracy
- ±2% of FS (3000-0 ±3% of FS). (3000-00 ±4% of FS).
- Pressure Limit
- -20" Hg. to 25 psig (-0.677 bar to 1.72 bar). MP option: 35 psig (2.41 bar), HP option: 80 psig (5.52 bar).
- Switch Type
- Each setpoint has a solid state relay.
- Relay Contacts
- (Resistive load) 1 form C rated 1.0A @ 30 VDC, 0.3A @ 110 VDC or 0.5A @ 125 VAC. Gold over clad silver - suitable for dry circuits.
- Temperature Limits
- 20 to 120°F (-6.67 to 48.9°C).
- Agency Approvals
- CE.
- Process Connections
- 1/8" female NPT (duplicated side and back).
- Power Requirements
- 24 VDC, regulated ±10%. 24VAC optional.
- Set Point Adjustment
- Adjustable knobs on face.
- Switching Current
- 1.0 amp (AC) max., 0.01 mA (AC) min., (2) SPST NO.
- Service
- Air and non-combustible, compatible gases.
- Mounting Orientation
- Diaphragm in vertical position. Consult factory for other position orientations.
- Switching Voltage
- 20-280 VAC (47-63 Hz).
Description
Pressure switch/gage, range 0-50 mm w.c., 1.0 minor divisions.
