Pressure Transmitter, 0-1500psi, 36In Lead

Zoro #: G0056551
Mfr #: 626-16-GH-P1-E1-S1

Hover or click to zoom Tap to zoom

Key Features

Process Connection: 1/4 in MNPT
Process Connection Type - Transmitter: MNPT
Process Connection Size - Transmitter: 1/4 in
Operating Temp.: 0 to 200 F
Output - Transmitter: 4 to 20mA DC
Range Units - Transmitter: psi
Power Required - Transmitters: 13 to 30V DC
Accuracy - Transmitter: +/-0.25% Full Scale

See full product details

$316.78

35% off

$203.49

Quantity

For 10% Off Your First Order

30-Day Returns

125 U.S.-Based Customer Service Agents

Dwyer #626-16-GH-P1-E1-S1 Specifications

Zoro #: G0056551
Mfr #: 626-16-GH-P1-E1-S1

Process Connection: 1/4 in MNPT
Process Connection Type - Transmitter: MNPT
Process Connection Size - Transmitter: 1/4 in
Operating Temp.: 0 to 200 F
Output - Transmitter: 4 to 20mA DC
Range Units - Transmitter: psi
Power Required - Transmitters: 13 to 30V DC
Accuracy - Transmitter: +/-0.25% Full Scale
Loop Resistance: 0 to 1300 ohms
Accuracy: +/-0.25%
Electrical Connections - Transmitter: 3 ft Cable
Includes: Instructions
NEMA Rating: NEMA 4X
Output: 4 to 20 mA DC
Operating Temp. - Transmitter: 0 Degrees to 200 Degrees F
Housing: Stainless Steel
Wetted Materials: 316 SS and 316L SS
Wetted Materials - Transmitters: 316 Stainless Steel, 316L Stainless Steel
Power Required: 13 to 30VDC
Range Values - Transmitter: 0 to 1500
Electrical Connections: 36" Wire
Thermal Error: +/-0.02%
Compatible With: Liquids and Gas
Lead Length (In.): 36
Range: 0 to 1500 psi
Manufacturers Warranty Length: 1 yr
Item: Pressure Transmitter
Max. Pressure (PSI): 3,000 psi
Wiring Entry - Transmitter: 1/2 in FNPT
Transmitter Type: Pressure Transmitter
Process Connection Type: NPT
Cable Length: 3 ft
Overall Length: 1.281 in
Standards: CE, NSF, UL Listed
Minimum Operating Temperature: 0 Degrees F
Operating Temperature: 0 Degrees F to 200 Degrees F
Explosion/Fire Proof: No
Electrical Connection: Cable & Wire Leads
Overall Height: 3.5 in
Overpressure: 5,000 psig
Process Connection Size: 1/4 in
Enclosure Rating: IP66 ; NEMA 4X
Overall Width: 5.5 in
Housing Material: Stainless Steel
Response Time: 300 msec
Minimum Pressure: 0 psi
Pressure Units: psig
Type of Pressure: Gauge
Maximum Operating Temperature: 200 Degrees F
Maximum Pressure: 1,500 psi
Pressure Range: 0 psi to 1,500 psi
Number of Wires: 2
(hidden) connection builder: Cable & Wire Leads x Cable Gland
Wiring Entry: Cable Gland
Maximum Loop Resistance: 0 to 1,000 Ohm Max
NIST Traceable Certificate: No
Intrinsically Safe: No
IP Rating: IP66
Weight: 10 oz
Process Connection Gender: Male
For Use With Media Type: Compressors, Hydraulics, Pumps
Series: 626
Country of Origin (subject to change): United States

Description

Pressure Transmitter, Minimum Pressure 0 psi, Maximum Pressure 1,500 psi, Electrical Connections Cable & Wire Leads, Output 4 to 20mA DC, Accuracy +/-0.25 Percent of Full Scale, Number of Wires 2, Process Connection Gender Male, Process Connection Size 1/4 in, Process Connection Type NPT, Power Required 10 to 30V DC, NEMA Rating NEMA 4X, IP Rating IP66, Series 626, Wiring Entry Cable Gland, Maximum Operating Temperature 200 Degrees F, Minimum Operating Temperature 0 Degrees F
