Dynabrade Air Drill, Industrial, In-Line, 1/4 In. 53078 - main

Air Drill, Industrial, In-Line, 1/4 In.

  • Mfr # 53078

  • Zoro # G6610256

product price: $727.99
/ea
Free Shipping & Returns

Key Features

HP
0.4
HP - Air Tools
0.40
Chuck Size - Air Drills
1/4 in
Air Inlet
1/4 in NPT
Drill Chuck Type - Air Drills
Keyed
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
53078
Zoro #
G6610256
UPC #
616026530782
Country of Origin
United States

Dimensions

Chuck Size - Air Drills
1/4 in
Min. Hose Size
1/4 in
Overall Length
10 1/2 in
Chuck Size
1/4 in
Air Inlet Size - Air Tools
1/4 in NPT
Overall Height
1 5/8 in
Overall Width
1 5/8 in
Spindle Thread Size
3/8"-24

Details

Item
Drill
HP
0.4
HP - Air Tools
0.40
Air Inlet
1/4 in NPT
Drill Chuck Type - Air Drills
Keyed
Required Pressure
90 PSI
Free Speed
3,200 RPM
Duty Cycle - Air Tools
Industrial Duty
Torque
1.20 ft-lb
Throttle Type
Lever
Tool Weight
1.8 lb
Drill Chuck Type
Keyed
Duty
Industrial
Body Style - Air Tools
Inline
Includes
1/4 in Drill Chuck and Chuck Key
Style
In-Line
Handle Material
Rubber
Variable Speed
No
Item - Air Drills
Air Drill
Gear Train
Planetary
Average CFM @ 15 Second Run Time
3.10
Bearings
Ball
Housing Material
Composite
Handle Type
Inline
Side to Center
7/8 in
Drilling Capacity in Masonry
5/8 in
Air Consumption
22 cfm
Duty Rating
Industrial Duty
Bearing Design
Ball
Number of Speed Settings
Continuous
Noise Level
77 dB
Exhaust Location
Rear
Max. Torque
4.9 ft-lb
Torque Range
1.6 ft-lb to 4.9 ft-lb
Chuck Material
Metal/Plastic
Air Pressure
90 psi
Vibration Level
2.3 m/sq sec
Min. Torque
1.6 ft-lb
Drilling Capacity in Steel
5/8 in
Drilling Capacity in Cast Iron
5/8 in
Drilling Capacity in Aluminum
5/8 in
Reversible
No
Drilling Capacity in Wood
5/8 in
Horsepower
0.4 hp
Power Source
Air-Powered

Description

Air-Powered Drill, HP - Air Tools 0.40, Chuck Size - Air Drills 1/4 in, Drill Chuck Type - Air Drills Keyed, Inline Body Style - Air Tools, Free Speed 3,200 RPM, Industrial Duty Duty Cycle - Air Tools, Torque 1.20 ft-lb, Air Inlet Size - Air Tools 1/4 in NPT, Average CFM @ 15 Second Run Time 3.10, Required Pressure 90 psi, Min. Hose Size 1/4 in, Handle Material Rubber, Variable Speed No, Throttle Type Lever, Bearings Ball, Housing Material Composite, Gear Train Planetary
