Dynaquip Controls 2" FNPT Bronze Pneumatic Ball Valve Inline PVA68AMDA063A - main

2" FNPT Bronze Pneumatic Ball Valve Inline

  • Mfr # PVA68AMDA063A

  • Zoro # G2126591

product price: $687.99
/ea
Free Shipping & Returns

Key Features

Body Material
Bronze
Standards
TSSA, MSS-SP 110, CSA
Overall Length
5.39 in
Body Style
Inline
Port
Full
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PVA68AMDA063A
Zoro #
G2126591
UPC #
649848046599
Country of Origin
Taiwan, Province of China

Dimensions

Overall Length
5.39 in
Pipe Size
2 in
Connection Size - Side 1
2 in
Connection Size - Side 2
2 in
Nominal Valve Size
2 in

Details

Item
Pneumatically Actuated Two-Way Ball Valve
Body Material
Bronze
Standards
TSSA, MSS-SP 110, CSA
Body Style
Inline
Port
Full
Connection Type
FNPT
Ball Valve Product Group
Actuated
Body Seal Material
PTFE/Viton
Seat Material
PTFE
Max. Inlet Pressure
300 psi
Max. Pressure
600 psi CWP
Mount
Direct
Required Pressure
80 psi
Stem Material
316 Stainless Steel
Ball Valve Basic Body Material
Bronze
Operation
Double Acting
Valve Structure
3-Piece
Temp. Range
-4 Degrees to 176 Degrees F
Ball Material
316 Stainless Steel
Seal Material
PTFE, FKM
Valve Deactivated State
Normally Closed (NC), Normally Open (NO)
Manufacturer Warranty
2 yr
Actuator Series
HP
Maximum Pressure - Steam
125 psi
Maximum Pressure - Combustible Gas
Not Rated
Included Mounting
ISO 5211 Actuator Mounting Pad
Operating Temperature - Minimum
-20 Degrees F
Operating Temperature - Maximum
400 Degrees F
Coefficient of Volume (Cv)
270
Actuator Air Pressure - Minimum
80 psi
Valve Body Style
Straight
Valve Construction
Three-Piece
Connection Gender - Side 2
Female
Connection Gender - Side 1
Female
Vacuum Service Rating
29 in Hg
For Media
Air, Oil, Water
Actuator Features
Position Indicator
Maximum Operating Pressure Differential
300 psi
Connection Type - Side 2
NPT
Ball Port Style
Full Port
IP Rating
IP65
Maximum Pressure - Operating
600 psi
Actuator Ambient Temperature - Maximum
176 Degrees F
Connection Type - Side 1
NPT
3-A Standard Compliance
Not Rated
Vented Ball Valve
Non-Vented
Actuator Operation
Air to Air
Included Pilot Solenoid
115V AC Pilot Solenoid
Fail Safe Position
Fail Last
Actuator Air Pressure - Maximum
300 psi
Valve Ways
2-Way
Actuator Ambient Temperature - Minimum
-4 Degrees F
NEMA Enclosure Rating
4, 4X
Valve Series
PVA

Description

Pneumatically Actuated Two-Way Ball Valve, Nominal Valve Size 2 in, Actuator Operation Air to Air, Ball Material 316 Stainless Steel, Valve Deactivated State Normally Closed (NC), Normally Open (NO), Fail Safe Position Fail Last, Included Pilot Solenoid 115V AC Pilot Solenoid, Valve Body Style Straight, Body Material Bronze, Average Surface Roughness (Ra) Not Applicable, Ball Port Style Full Port, Maximum Pressure - Operating 600 psi, Maximum Pressure - Steam 125 psi
