2NC Limit Switch Body Nema 1, 2, 4, 4X, 6, 12, 13

  • Mfr # LS-S02
  • Zoro # G6902856
product price:
$
66.59
/ea

Key Features

For Use With
Titan Limit Switch
NEMA Rating
1, 12, 13, 2, 4, 4X, 6
Contact Form
2NC
Electrical Connection
Screw Terminal
IP Rating
IP66, IP67
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LS-S02
Zoro #
G6902856
UPC #
786685392493
Country of Origin
Germany

Dimensions

Product Height
1.32 in
Product Length/Depth
2.99 in
Product Width
1.22 in
Manufacturer Warranty Length
1 yr
Overall Width
1.22 in
Overall Depth
2.99 in
Mounting Hole Diameter
0.16 in
Overall Height
1.32 in

Details

Item
Limit Switch Body
For Use With
Titan Limit Switch
NEMA Rating
1, 12, 13, 2, 4, 4X, 6
Contact Form
2NC
Electrical Connection
Screw Terminal
IP Rating
IP66, IP67
Operating Temp.
-13 Degrees to 158 Degrees F
Standards
RoHS, UL Listed
AC Contact Rating
6 A @ 230 V
Series
LS-Titan
Material
Plastic
DC Contact Rating
3 A @ 24 V
Accuracy
±0.02mm
Output
2 NC with positive opening contacts
Certifications
UL Listed
Type
LS-Titan
Connection
Screw terminal
Maximum DC current
3 A at 24 Vdc
Operating temperature - max
158°F
Operating temperature - min
-13°F
Contact Rating
6A at 230 Vac, 3A at 24 Vdc
Contact configuration
2 NC with positive opening contacts
Environmental rating
IP66, IP67
Operating speed
99.97 cm/sec
Enclosure material
Plastic
Maximum AC current
6 A at 230 Vac
Product Name
Eaton LS-Titan Key interlock safety switches
Operating Temperature - Minimum
-13 Degrees F
Compatible with Series
LS-Titan
NEMA Enclosure Rating
1, 12, 13, 2, 4, 4X, 6
Number of Mounting Holes
2
Mounting Hole Horizontal Center to Center Distance
20 mm
Operating Temperature - Maximum
158 Degrees F
Shell Material
Plastic
Compatible Series
LS-Titan

Description

Limit Switch Body, Contact Form 2NC, For Use With Titan Limit Switch, AC Contact Rating 6 A @ 230 V, NEMA Rating 1, 12, 13, 2, 4, 4X, 6, Electrical Connection Screw Terminal, IP Rating IP66, IP67, Operating Temp. -13 Degrees to 158 Degrees F, Standards RoHS, UL Listed
