  15. 2NC/2NO Limit Switch Body Nema 1, 2, 4, 6, 6P, 12, 13
Eaton 2NC/2NO Limit Switch Body Nema 1, 2, 4, 6, 6P, 12, 13 E50SB6PC - main

2NC/2NO Limit Switch Body Nema 1, 2, 4, 6, 6P, 12, 13

  • Mfr # E50SB6PC

  • Zoro # G5232132

product price: $623.99
/ea
Free Shipping & Returns

Key Features

For Use With
E50 Limit Switch
NEMA Rating
1, 12, 13, 2, 4, 6, 6P
AC Contact Rating
10 A @ 240 V
Contact Form
2NO/2NC
Operating Temp.
14 Degrees to 221 Degrees F
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
E50SB6PC
Zoro #
G5232132
UPC #
782113727851
Country of Origin
Mexico

Dimensions

Product Height
2.46 in
Product Length/Depth
4.24 in
Product Width
1.54 in
Overall Width
1.54 in
Manufacturer Warranty Length
1 yr
Overall Height
2.46 in
Mounting Hole Diameter
0.2 in
Overall Depth
4.24 in

Details

Item
Limit Switch Body
For Use With
E50 Limit Switch
NEMA Rating
1, 12, 13, 2, 4, 6, 6P
AC Contact Rating
10 A @ 240 V
Contact Form
2NO/2NC
Operating Temp.
14 Degrees to 221 Degrees F
Standards
CSA, RoHS, UL Listed
Electrical Connection
8 ft Cable with Pre-Terminated 9-Pin Mini Connector
IP Rating
IP67, IP69K
DC Contact Rating
1 A @ 250 V
Material
Zinc
Series
E50
Maximum DC current
1 A
Environmental rating
NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67, IP69K
Certifications
UL Recognized
Enclosure material
Die cast zinc
Operating temperature - min
-40°F
Contact Rating
10A at 240 Vac, 1A at 250 Vdc
Operating temperature - max
250°F
Number of pins
5
Contact configuration
2 NO-2 NC
Maximum AC current
10 A
Connection
Mini
Product Name
Eaton E50 NEMA heavy duty plug-in limit switch
NEMA Enclosure Rating
1, 13, 3, 3S, 4, 4X, 6, 6P
Operating Temperature - Maximum
250 Degrees F
Mounting Hole Vertical Center to Center Distance
60 mm
Number of Mounting Holes
2
Indicating Light
No Indicating Light Included
Compatible with Series
E50
Body Configuration
Plug-In
Operating Temperature - Minimum
-40 Degrees F
Mounting Hole Horizontal Center to Center Distance
30 mm

Description

Limit Switch Body, Contact Form 2NO/2NC, For Use With E50 Limit Switch, AC Contact Rating 10 A @ 240 V, NEMA Rating 1, 12, 13, 2, 4, 6, 6P, Electrical Connection 8 ft Cable with Pre-Terminated 9-Pin Mini Connector, IP Rating IP67, IP69K, Operating Temp. 14 Degrees to 221 Degrees F, Standards CSA, RoHS, UL Listed
