480VAC Reversing Magnetic Contactor 3P 45A NEMA 2
Mfr # CN55GN3CB
Zoro # G3636647
product price: $2,389.99
/ea
Free Shipping & Returns
Key Features
Action
Reversing
Full Load Amps
45 A
Number of Poles
3
NEMA Contactor Size
2
Reversing
Yes
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
CN55GN3CB
Zoro #
G3636647
UPC #
782113001630
Country of Origin
United States
Dimensions
NEMA Contactor Size
2
Height
6.5 in
Width
7.3 in
Depth
7.7 in
NEMA Size
2
Product Length/Depth
4.44 in
Size
2
Product Height
5.05 in
Product Width
2.56 in
Overall Depth
4.44 in
Mounting Hole Diameter
0.25 in
Mounting Hole Distance - Height
4.5 in
Overall Height
5.05 in
Mounting Hole Distance - Width
2 in
Overall Width
2.56 in
Frame Size
G
Description
NEMA Magnetic Contactor, Auxiliary Contact Form 1NO/1NC, NEMA Enclosure Rating No Enclosure, NEMA Size 2, Coil Voltage 440/480V AC, Number of Poles 3, Full Load Current - Inductive 45 A, Reversing Capability Reversing, Overall Height 5.05 in, Overall Width 2.56 in, Terminal Connection Type Screw Terminals, Frame Size G, Mounting Style Panel, Series Freedom, Number of Auxillary Contacts 2, Contactor Style NEMA, Horsepower @ Three Phase - 240V AC 15 hp, Horsepower @ Three Phase - 480V AC 25 hp
