Glass Fuse, S500 Series, Fast-Acting, 0.25A, 250V AC, Non-Indicating, 100 PK
Mfr # BK/S500-250-R
Zoro # G804217762
product price:Â
$
399.99
/pk of 100, $4.00/ea
Free Shipping & Returns
Key Features
Series
S500
Speed
Fast-Acting
AC Voltage Rating
250V AC
Visual Indication
Non-Indicating
Interrupt Rating
35A at 250V AC
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- BK/S500-250-R
- Zoro #
- G804217762
- UPC #
- 051712643412
- Country of Origin
- China
Dimensions
- Diameter
- 5 mm
- Length
- 20 mm
- Cap Diameter
- 5 3/16 in
- Overall Length
- 20 mm
- Overall Diameter
- 5 mm
- Wire Rope Length
- 20 mm
Details
- Series
- S500
- Speed
- Fast-Acting
- Amps
- 0.25A
- AC Voltage Rating
- 250V AC
- Visual Indication
- Non-Indicating
- Interrupt Rating
- 35A at 250V AC
- Body Style
- Cylindrical
- Body Material
- Glass
- Equivalent Brand and Series
- Bussmann S500
- Compatible Fuse Block Series
- 1A3399, H15, HHT, HTB, HTC-15M
- DC Voltage Rating
- 32V DC
- Item
- Glass Fuse
- Standards
- BSI Approval File KM55676, CCC Approval File 2005010207155694, CSA Component Acceptance File 1803366, cURus File E19180 Guide JDYX2, IEC 60127-2, IMQ Approval File CA03.00097, JDYX8, SEMKO Approval File 414552, VDE Approval File 40014109
- Equivalent Series
- 217, GDB, GSB, S500
- Interrupt Rating - AC
- 35 A
- Current
- 250 mA
Description
Fuse, 0.25 A, 250 V AC, Not Applicable, S500 Series, Glass Fuse, Fast-Acting, Body Style Cylindrical, Interrupt Rating 35 A at 250V AC, Fuse Size 20.00 mm L x 5.00 mm dia, Length 20 mm, Diameter 5 mm, Equivalent Brand and Series Bussmann S500, Equivalent Series 217, GDB, GSB, S500, Body Material Glass, Compatible Fuse Block Series 1A3399, H15, HHT, HTB, HTC-15M, Cap Diameter 5 3/16 in
