Open Fuse Block, 40 to 80A Amp Range, 32V DC Volt Rating, 1 Poles, Screw

  • Mfr # HMID
  • Zoro # G5413969
product price:
$
16.45
/ea

Key Features

Series
HMID
Number of Poles
1
Amp Range
40 to 80A
Voltage Rating
32V DC
Connector Type
Screw
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
HMID
Zoro #
G5413969
UPC #
051712614627
Country of Origin
Mexico
Item
Open Fuse Block
Series
HMID
Number of Poles
1
Amp Range
40 to 80A
Voltage Rating
32V DC
Connector Type
Screw
Mounting Style
Bolt-Down
Visual Indication
Non-Indicating
Fuse Block Style
Non-Rejection
Fuse Block Design
Covered
Body Material
Thermoplastic
Features
Cover
Fuse Type
Automotive
For Fuse Series
AMI
Wire Range
8 AWG to 1 AWG
Fits Fuse Type
Automotive
Weight
.76 lb
Fits Fuse Block Style
Non-Rejection
Current - Minimum
40 A
Current - Maximum
80 A
DC Voltage Rating
32 V DC

Dimensions

Wire Size
8 to 1 AWG
Length
2.03 in
Height
1 in
Width
1.10 in
For Fuse Size
1-39/64 in L x 13/32 in dia
Wire Size - Minimum
8 AWG
For Fuse Length
40 mm
Overall Height
1 in
Overall Length
2.03 in
Overall Width
1.1 in
For Fuse Width
12 mm
Wire Size - Maximum
1 AWG
Wire Rope Length
2.03 in
Fits Chest Size
Cover

Description

Fuse Block, Fits Fuse Type Automotive, Fuse UL Class Not Class Rated, 40 to 80 A, Number of Poles 1, 32V DC, For Fuse Size 1 39/64 in L x 15/32 in W x 11/32 in D, Compatible Fuse Series 498, AMI, Series HMID, Non-Indicating, Non-Rejection, Fuse Block Design Covered, Wire Range 8 to 1 AWG, Mounting Style Bolt-Down, Body Material Thermoplastic, Connector Type Screw, Height 1 in, Width 1.1 in, Length 2.03 in, Features Cover
