Eaton Control Relay, 12 Inputs, 4 Outputs EASY-E4-DC-12TC1 - main

Control Relay, 12 Inputs, 4 Outputs

  • Mfr # EASY-E4-DC-12TC1

  • Zoro # G4451588

product price: $326.99
/ea
Free Shipping & Returns

Key Features

Power Required
24V DC
Height
3.54 in
For Use With
EasySoft PLC Software
Number of Inputs
4, 8
Width
2.81 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
EASY-E4-DC-12TC1
Zoro #
G4451588
UPC #
-
Country of Origin
Germany

Dimensions

Height
3.54 in
Width
2.81 in
Depth
2.35 in
Overall Width
2.83 in
Overall Height
3.54 in
Overall Depth
2.28 in

Details

Power Required
24V DC
For Use With
EasySoft PLC Software
Number of Inputs
4, 8
Item
Control Relay
Number of Outputs
4
Includes
Screw Terminals
Features
Display Indication of 6 Lines x 16 Characters, Expandable, Inductive Load with External Suppressor Circuit, Networkable, Parallel Connection of Transistor Outputs with Resistive Load
Output Type
(4) Transistor
Input Voltage
24V AC/DC
Timers
32
Slots
Expand Up to 188 I/O
Description/Special Features
Analog Available, Ethernet Built-in, Many Accessories Available, Real Time Clock, High Speed Counters
Clock
Yes
Port Type
Ethernet Port Built-in, MicroSD Memory Card Slot, Modbus, Webserver
Display
LCD
Counters
36
Product Type
Control Relay
Output Circuit Voltage - Maximum
2.5 V
Output Circuit Current - Maximum
2 A
DC Voltage Rating
24V DC
Number of Timers
32
Input Type
(8) Digital
AC Voltage Rating
24V AC
Mounting Style
DIN Rail
Input Circuit Current - Maximum
80 mA
Communication Protocol
Modbus TCP/IP
Number of Slots
188
Current
500 mA
Number of Counters
36
Input Circuit Current - Minimum
1 mA
Clock Included
Clock Included
Series
Moeller
Input Circuit Voltage - Maximum
24 V DC
Display Type
LCD
Expandability
Expandable

Description

Control Relay, Input Voltage 24V AC/DC, Output Type (4) Transistor, Expand Up to 188 I/O Slots, Number of Inputs 4, 8, Number of Outputs 4, Counters 36, Timers 32, Yes Clock, LCD Display, Port Type Ethernet Port Built-in, MicroSD Memory Card Slot, Modbus, Webserver, Analog Available, Ethernet Built-in, Many Accessories Available, Real Time Clock, High Speed Counters, Depth 2.35 in, Height 3.54 in, Width 2.81 in
