  13. Cutler-Hammer Limit Switch Head, Plunger, Side, .20 In
Shop All Limit Switch Heads
Eaton

Cutler-Hammer Limit Switch Head, Plunger, Side, .20 In

product price: $139.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Actuator Style Rotary Lever
  • Actuator Location Side
  • Actuator Length 0.2 in
  • For Use With Mfr. No. E50SA
  • NEMA Rating 1, 12, 13, 2, 4, 4X, 6P
See all product information

Product Information

Dimensions

Actuator Length 0.2 in
Product Height 2.46 in
Product Length/Depth 1.05 in
Product Width 1.54 in
Overall Depth 1.05 in
Manufacturer Warranty Length 1 yr
Overall Width 1.54 in
Arm Length - Maximum 0.2 in
Overall Height 2.46 in

Details

Item Limit Switch Head
Actuator Style Rotary Lever
Actuator Location Side
For Use With Mfr. No. E50SA
NEMA Rating 1, 12, 13, 2, 4, 4X, 6P
Movement Side
Travel Operating Travel 5 Degrees , Reset Travel 2 Degrees , Total Travel 90 Degrees
IP Rating IP67
Voltage Rating 600V AC
Operating Temp. 14 Degrees to 200 Degrees F
Description/Special Features Maintained
Amps 10
Operating Force 0.7 N
Standards CSA, RoHS, UL Listed
Enclosure material Die cast zinc
Series E50
Certifications UL Listed
Switch type Neutral position 5° travel
Operating temperature - min 14°F
Type Limit Switch Head
Environmental rating NEMA 1, NEMA 3, NEMA 3S, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 13, IP67
Operating temperature - max 201°F
Product Name Eaton E50 NEMA heavy duty plug-in limit switch
Reset Travel 2 Degrees
Total Travel 90 Degrees
Directional Movement CCW/Center Neutral/CW
Compatible with Brand Eaton
Action Maintained
Operating Temperature - Minimum 14 Degrees F
NEMA Enclosure Rating 1, 13, 3, 3S, 4, 4X, 6, 6P
Differential Travel 90 Degrees
Overtravel 5 Degrees
Operating Torque 1.8 in-lb
Operating Temperature - Maximum 201 Degrees F
Compatible with Series E50
Pretravel 5 Degrees
Compatible with Manufacturer Model Number E50SA
Includes Actuator No Actuator Included

Description

Limit Switch Head, Actuator Style Rotary Lever, Actuator Location Side, Actuator Length 0.2 in, Contact Form Not Applicable, Amps 10, Voltage Rating 600V AC, Travel Operating Travel 5 Degrees , Reset Travel 2 Degrees , Total Travel 90 Degrees , Movement Side, Operating Force 0.7 N, Operating Temp. 14 Degrees to 200 Degrees F, NEMA Rating 1, 12, 13, 2, 4, 4X, 6P, IP Rating IP67, Standards CSA, RoHS, UL Listed, For Use With Mfr. No. E50SA
