  6. Diffuse Photoelectric Sensor, Bare Wire, Straight, Cylindrical, Selectable Light On/Dark On, NPN and PNP
Eaton Diffuse Photoelectric Sensor, Bare Wire, Straight, Cylindrical, Selectable Light On/Dark On, NPN and PNP 13104A6517 - main

Diffuse Photoelectric Sensor, Bare Wire, Straight, Cylindrical, Selectable Light On/Dark On, NPN and PNP

  • Mfr # 13104A6517

  • Zoro # G1997502

product price:  $257.99
/ea
Free Shipping & Returns

Key Features

Sensing Method
Diffuse
Electrical Connection
Bare Wire
Style
Cylindrical
Width
3.46"
Orientation
Straight
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
13104A6517
Zoro #
G1997502
UPC #
-
Country of Origin
Mexico

Dimensions

Width
3.46"
Depth
0.47"
Overall Diameter
18 mm
Cable Length
2 m
Length - Cylindrical Photoelectric Sensor
66 mm
Length
2.60"
Diameter
18mm
Min. Object Size
Adjustable By Changing Gain
Diameter - Cylindrical Photoelectric Sensor
18 mm
Overall Height
51 mm
Product Length/Depth
158.75 mm
Sensor length
66 mm
Wavelength of the sensor
0 nm
Wire size
22
Product Width
133.35 mm
Light dot size
0 mm²
Product Height
50.8 mm
Overall Depth
159 mm
Sensor Diameter
18 mm
Overall Width
133 mm

Details

Item
Photoelectric Sensor
Sensing Method
Diffuse
Electrical Connection
Bare Wire
Style
Cylindrical
Orientation
Straight
Operating Mode
Selectable Light On/Dark On
IP Rating
IP69K
Output Circuit Type
NPN and PNP
DC Voltage Rating
10-30V DC
Standards
CE, CSA C22.2 No.14, CSA, CSA 3211-07, CSA 50513, cUL Recognized, IEC/EN 60947-5-2, UL 508, UL NRKH, UL NRKH7, UL E117028, UL Listed
Response Time
1 msec
Max. Load Current
250 mA
Max. Sensing Distance
50mm
Operating Temp. Range
-40 Degrees to 70 Degrees C
Body Material
Polyurethane
Response Time (ms)
1
Features
Auto Reset Short Circuit
Operating Frequency
500 Hz
Power Requirement - Cylindrical Photoelectric Sensor
10 to 30V DC
Power Requirement
10 to 30VDC
Max. Sensing Distance - Cylindrical Photoelectric Sensor
50 mm
Light Source
Red LED
Enclosure Material
Polyurethane foam (RIM)
Triangulation
Background fade-out
Output current (mA) - max
250 mA
Load current
Max. 250 mA (Ie, NPN, 120 > 50°C)
Contact Rating
100 mA PNP, 250 mA NPN at 10-30 Vdc
Switching distance - max
50 mm
Voltage rating - max
30 V
Number of outputs (semiconductor with signaling function)
2
Switching Frequency
500 Hz
Transmission range of the safety field
0 m
Shock Resistance
100 g, Mechanical, Shock duration 3 ms
Input voltage
10-30 Vdc
Cable sheath material
Polyvinyl chloride (PVC)
Cable type
Polyvinyl Chloride (PVC)
Fitted with
Background suppression (Perfect Prox)
Switching voltage of OSSD at state high
30 V
Number of outputs (protected semiconductor)
0
Operational current (Ib) in the switched state at 24 V DC
30 A
Rated control supply voltage (Us) at AC, 60 Hz - max
0 V
Rated switching distance (Sn)
50 mm
LED indicator
Output ON
Switch function type
Programmable/configurable
Switching output type
PNP
Enclosure type
Cylinder, screw-thread
Rated control supply voltage (Us) at DC - min
10 V
Type
Optical sensors
Rated control supply voltage (Us) at AC, 50 Hz - min
0 V
Contact configuration
NPN and PNP open collector
Rated control supply voltage (Us) at AC, 60 Hz - min
0 V
Optical surface material
Plastic
Operation agent-safety class
Safety class 2
Reflector distance - min
0 mm
Functions
Protection against polarity reversal
Ambient operating temperature - max
70°C
Rated control supply voltage (Us) at AC, 50 Hz - max
0 V
Number of contact energized outputs with signalling function
0
Ambient operating temperature - min
-40°C
Output current at protected output - max
0 mA
Rated control supply voltage (Us) at DC - max
30 V
Sensor material
Insulated material
Number of outputs (protected contact energized)
0
Voltage type
DC
Protection
Auto reset short circuit
Maximum DC current
100 mA PNP, 250 mA NPN
Sensing mode
Light-/dark switching
Sensing Distance - Minimum
10 mm
Operating Temperature - Minimum
-40 Degrees F
Electrical Installation Type
Prewired Cable
Includes Indicator Lights
Indicator Lights Included
Emitted Sensor Light
Red Light
Sensing Distance - Maximum
50 mm
NEMA Enclosure Rating
1, 12, 13, 3, 4, 4X, 6
Series
E58
Operating Temperature - Maximum
158 Degrees F
Load Current - Maximum
250 mA

Description

Photoelectric Sensor, Sensing Method - Cylindrical Photoelectric Sensor Diffuse, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Diameter - Cylindrical Photoelectric Sensor 18 mm, Power Requirement - Cylindrical Photoelectric Sensor 10 to 30V DC, Electrical Connection - Cylindrical Photoelectric Sensor 2m Cable, Circuit Type - Cylindrical Photoelectric Sensor NPN/PNP, Max. Sensing Distance - Cylindrical Photoelectric Sensor 50 mm
