IEC Magnetic Contactor, 1NC, 24V DC, 3 P, Non-Reversing, Screw

  • Mfr # XTCE007B01TD

  • Zoro # G1114373

product price:
$
109.99
/ea
Free Shipping & Returns

Key Features

Auxiliary Contact Form
1NC
Coil Voltage
24V DC
Number of Poles
3
Full Load Amps-Inductive
7 A
Full Load Amps-Resistive
22 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
XTCE007B01TD
Zoro #
G1114373
UPC #
786685363356
Country of Origin
Romania

Dimensions

Overall Width
1.77 in
Mounting Hole Distance - Height
2.36 in
Mounting Hole Diameter
0.16 in
Frame Size
B
Overall Depth
2.95 in
Mounting Hole Distance - Width
1.38 in
Overall Height
3 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NC
Coil Voltage
24V DC
Number of Poles
3
Full Load Amps-Inductive
7 A
Full Load Amps-Resistive
22 A
Reversing Capability
Non-Reversing
Terminal Connection Type
Screw
Number of Auxillary Contacts
1
Standards
CSA, UL Listed
Frame / Series / Class / Code
Frame B
Enclosure NEMA Rating
No Enclosure
Reversing
No
HP @ 3 Phase - 575V
5 hp
HP @ 1 Phase - 230V
1
Type
Full voltage non-reversing contactor
Series
XT
IP Rating
IP20
Contact Configuration
1 NC
Product Name
Eaton XT IEC contactor
Amperage Rating
7 A
Electrical Operating Durability
1000 (AC-3 400V Ie), 300 (AC-4 400V Ie), 800 (AC-1 400V Ie)
Horsepower @ Single Phase - 240V AC
1 hp
Includes Auxiliary Contacts
Yes
NEMA Enclosure Rating
No Enclosure
Maximum Voltage Rating
690V AC
Full Load Current - Inductive
7 A
Horsepower @ Single Phase - 120V AC
1/4 hp
Mechanical Operating Durability
10,000,000
Embedded Surge Suppressor
Yes
Maximum Operating Temperature
122 Degrees F
Horsepower @ Three Phase - 600V AC
5 hp
Contactor Style
IEC
Horsepower @ Three Phase - 208V AC
1 1/2 hp
Response Time
Less Than12 msec (DC Operated Opening Delay), Less Than18 msec (AC Operated Opening Delay), Less Than21 msec (AC Operated Closing Delay), Less Than31 msec (DC Operated Opening Delay)
Minimum Operating Temperature
-13 Degrees F
Frequency
50/60 Hz
Horsepower @ Three Phase - 240V AC
2 hp
Mounting Style
DIN Rail, Panel
Horsepower @ Three Phase - 480V AC
3 hp
Full Load Current - Resistive
22 A

Description

The Eaton XT IEC contactor is a 3-pole, non-reversing IEC magnetic contactor with a 24 V DC coil. It is rated for operation at the specified current levels and includes one NC auxiliary contact. The device uses screw terminals and supports DIN Rail or Panel mounting in frame size B (XT series). It carries UL Listed and CSA Certified marks and is designed for use within the specified voltage and frequency ranges, with IP20 protection and no enclosure.

Key features:

  • Poles: 3; Main contact configuration: 1 NC; Auxiliary contacts: 1 NC (Includes 1NC)
  • Coil voltage: 24 V DC
  • Electrical ratings: 7 A inductive, 22 A resistive (Full Load)
  • Durability: 10,000,000 electrical cycles; 10,000,000 mechanical cycles
  • Termination: Screw terminals
  • Mounting: DIN Rail, Panel
  • Frame/Series: XT series; Frame size B
  • Maximum voltage: 690 V AC; Frequency: 50/60 Hz
  • Enclosure/IP: IP20; No Enclosure
  • Certifications: UL Listed; CSA Certified
  • Temperature range: -13°F to 122°F
  • Dimensions: 2.95 in depth; 3.00 in height; 1.77 in width
  • Reversing: No (Non-Reversing)
