IEC Magnetic Contactor, 1NO, 24V DC, 3 P, Non-Reversing, Screw

  • Mfr # XTCE032C10TD

  • Zoro # G1056623

product price:
$
263.99
/ea
Free Shipping & Returns

Key Features

Auxiliary Contact Form
1NO
Coil Voltage
24V DC
Number of Poles
3
Full Load Amps-Inductive
32 A
Full Load Amps-Resistive
45 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
XTCE032C10TD
Zoro #
G1056623
UPC #
786685363158
Country of Origin
Romania

Dimensions

Product Length/Depth
4 in
Frame Size
C
Mounting Hole Distance - Height
2.95 in
Overall Depth
4 in
Overall Width
3.5 in
Mounting Hole Diameter
0.16 in
Mounting Hole Distance - Width
1.38 in
Overall Height
2 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NO
Coil Voltage
24V DC
Number of Poles
3
Full Load Amps-Inductive
32 A
Full Load Amps-Resistive
45 A
Reversing Capability
Non-Reversing
Terminal Connection Type
Screw
Number of Auxillary Contacts
1
Standards
CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
Frame / Series / Class / Code
Frame C
Reversing
No
HP @ 1 Phase - 230V
5
Enclosure NEMA Rating
No Enclosure
HP @ 3 Phase - 575V
25 hp
Series
XT
Type
Full voltage non-reversing contactor
IP Rating
IP20
Compliances
CE Marked
Contact Configuration
1 NO
Product Name
Eaton XT IEC contactor
Amperage Rating
32 A
Mounting Style
DIN Rail, Panel
Full Load Current - Resistive
45 A
NEMA Enclosure Rating
No Enclosure
Horsepower @ Three Phase - 480V AC
20 hp
Frequency
50/60 Hz
Horsepower @ Three Phase - 208V AC
10 hp
Electrical Operating Durability
300 (AC-4 400V Ie), 800 (AC-1 400V Ie), 800 (AC-3 400V Ie)
Minimum Operating Temperature
-13 Degrees F
Contactor Style
IEC
Maximum Operating Temperature
122 Degrees F
Horsepower @ Three Phase - 600V AC
25 hp
Horsepower @ Three Phase - 240V AC
10 hp
Embedded Surge Suppressor
Yes
Horsepower @ Single Phase - 240V AC
5 hp
Response Time
Less Than14 msec (AC Operated Opening Delay), Less Than22 msec (AC Operated Closing Delay), Less Than30 msec (DC Operated Opening Delay), Less Than47 msec (DC Operated Opening Delay)
Includes Auxiliary Contacts
Yes
Mechanical Operating Durability
10,000,000
Maximum Voltage Rating
690V AC
Horsepower @ Single Phase - 120V AC
3 hp
Full Load Current - Inductive
32 A

Description

The Eaton XT IEC contactor is a 3-pole, non-reversing IEC magnetic contactor with a 24V DC coil and one normally open auxiliary contact (1NO). It follows IEC standards (Frame Size C) and is rated for operation within specified power circuit parameters. The unit uses screw terminals and supports DIN rail or panel mounting. It has a rated current capacity of 32A (inductive) and 45A (resistive) under specified conditions, with operation at 50/60 Hz. It is rated for operation up to 690V AC within the specified voltage range. Certifications conform to applicable standards including UL Listed, CSA Certified, CE Marked, EN 60947, IEC 60947, and RoHS; includes an embedded surge suppressor.

Key features

  • Poles: 3
  • Coil: 24 V DC; Coil voltage: 24 V DC
  • Auxiliary contacts: 1 NO
  • Mounting: DIN Rail, Panel
  • Terminals: Screw
  • Frame/Series: Frame C; Series XT
  • Enclosure: No Enclosure; IP20
  • Certifications/Compliances: UL Listed; CSA Certified; CE Marked; EN 60947; IEC 60947; RoHS
  • Full-load currents: 32 A (inductive); 45 A (resistive)
  • Electrical durability: 300 (AC-4 400V Ie); 800 (AC-1 400V Ie); 800 (AC-3 400V Ie)
  • Mechanical durability: 10,000,000 cycles
  • Reversing: No
  • Maximum voltage: 690V AC
  • Response time: as specified (AC Opening <14 ms; AC Closing <22 ms; DC Opening <30 ms; DC Opening <47 ms)
