Eaton IEC Magnetic Contactor, No Auxiliary Contacts, 480V AC, 3 P, Non-Reversing, Screw XTCE170G00C - main

IEC Magnetic Contactor, No Auxiliary Contacts, 480V AC, 3 P, Non-Reversing, Screw

  • Mfr # XTCE170G00C

  • Zoro # G6362867

product price:  $1,046.99
/ea
Free Shipping & Returns

Key Features

Auxiliary Contact Form
No Auxiliary Contacts
Coil Voltage
480V AC
Number of Poles
3
Full Load Amps-Inductive
170 A
Full Load Amps-Resistive
190 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
XTCE170G00C
Zoro #
G6362867
UPC #
786685213699
Country of Origin
Germany

Dimensions

Frame Size
G
Product Length/Depth
3.583 in
Mounting Hole Diameter
0.24 in
Mounting Hole Distance - Height
6.14 in
Overall Height
6.89 in
Overall Width
6.73 in
Mounting Hole Distance - Width
2.79 in
Overall Depth
3.58 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
No Auxiliary Contacts
Coil Voltage
480V AC
Number of Poles
3
Full Load Amps-Inductive
170 A
Full Load Amps-Resistive
190 A
Reversing Capability
Non-Reversing
Terminal Connection Type
Screw
Number of Auxillary Contacts
0
Standards
CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
HP @ 3 Phase - 575V
125 hp
Frame / Series / Class / Code
Frame G
Reversing
No
Enclosure NEMA Rating
No Enclosure
HP @ 1 Phase - 230V
30
Series
XT
Type
Full voltage non-reversing contactor
IP Rating
IP20
Product Name
Eaton XT IEC contactor
Amperage Rating
170A
Contact Configuration
0 NO, 0 NC
Compliances
CE Marked
Mechanical Operating Durability
10,000,000
Horsepower @ Single Phase - 120V AC
10 hp
Full Load Current - Resistive
190 A
Minimum Operating Temperature
-13 Degrees F
Frequency
50/60 Hz
Maximum Voltage Rating
690V AC
Horsepower @ Three Phase - 208V AC
40 hp
Electrical Operating Durability
300 (AC-4 400V Ie), 800 (AC-1 400V Ie), 800 (AC-3 400V Ie)
NEMA Enclosure Rating
No Enclosure
Full Load Current - Inductive
170 A
Horsepower @ Three Phase - 240V AC
60 hp
Response Time
Less Than30 msec (DC Operated Opening Delay), Less Than33 msec (AC Operated Closing Delay), Less Than35 msec (DC Operated Closing Delay), Less Than41 msec (AC Operated Opening Delay)
Horsepower @ Three Phase - 600V AC
125 hp
Contactor Style
IEC
Horsepower @ Single Phase - 240V AC
30 hp
Horsepower @ Three Phase - 480V AC
125 hp
Embedded Surge Suppressor
Yes
Includes Auxiliary Contacts
No
Phase
3
Maximum Operating Temperature
122 Degrees F
Mounting Style
DIN Rail, Panel

Description

The Eaton XT IEC contactor is a three-pole, non-reversing IEC magnetic switch with a 480 V AC coil. It uses screw terminals and has no auxiliary contacts. Part of the XT series (Frame G), compatible with DIN Rail or Panel mounting as specified, rated for operation within the specified load conditions, and rated for operation within the specified voltage and frequency ranges. It conforms to IP20 ingress protection standards when installed accordingly.

Action: Non-Reversing

  • Reversing: No
  • Poles: 3
  • Coil voltage: 480 V AC
  • Amperage rating: 170 A (full-load inductive); 190 A (full-load resistive)
  • Auxiliary contacts: No auxiliary contacts
  • Frame: G
  • Series: XT
  • Termination: Screw terminals
  • Enclosure: No Enclosure
  • IP rating: IP20
  • Maximum voltage rating: 690 V AC
  • Frequency: 50/60 Hz
  • Certifications: IEC 60947; CSA Certified; EN 60947; UL Listed; CE Marked; RoHS
  • Mechanical durability: 10,000,000 cycles
  • Electrical durability: 300 (AC-4 400V Ie); 800 (AC-1 400V Ie); 800 (AC-3 400V Ie)
  • Operating temperature: -13°F to 122°F
  • Mounting: DIN Rail; Panel
  • Dimensions: 6.89 in H x 6.73 in W x 3.58 in D
  • Mounting hole diameter: 0.24 in
  • Response time: DC opening <30 ms; AC closing <33 ms; DC closing <35 ms; AC opening <41 ms
  • Product name: Eaton XT IEC contactor
