  11. Polarized Retroreflective Photoelectric Sensor, Bare Wire, Right Angle, Rectangular, Selectable Light On/Dark On, SPST
Eaton Polarized Retroreflective Photoelectric Sensor, Bare Wire, Right Angle, Rectangular, Selectable Light On/Dark On, SPST 1451E-6513 - main

Polarized Retroreflective Photoelectric Sensor, Bare Wire, Right Angle, Rectangular, Selectable Light On/Dark On, SPST

  • Mfr # 1451E-6513

  • Zoro # G1767647

product price: $208.99
/ea
Free Shipping & Returns

Key Features

Width
1.81"
Depth
1.91"
Light Source
Red LED
Operating Frequency
250 Hz
Operating Temp. Range
-25 Degrees to 55 Degrees C
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
1451E-6513
Zoro #
G1767647
UPC #
-
Country of Origin
China

Dimensions

Width
1.81"
Depth
1.91"
Min. Object Size
Adjustable By Changing Gain
Width - Rectangular Photoelectric Sensor
46 mm
Depth - Rectangular Photoelectric Sensor
48 mm
Height - Rectangular Photoelectric Sensor
88 mm
Length
3.46"
Overall Height
46 mm
Cable Length
2 m
Product Length/Depth
3.46 in
Product Width
1.91 in
Product Height
1.81 in
Overall Depth
88 mm
Overall Width
49 mm

Details

Item
Photoelectric Sensor
Light Source
Red LED
Operating Frequency
250 Hz
Operating Temp. Range
-25 Degrees to 55 Degrees C
Power Requirement - Rectangular Photoelectric Sensor
24 to 240V AC/12 to 240V DC
Max. Sensing Distance
4900mm
Electrical Connection
Bare Wire
Power Requirement
24 to 240VAC/12 to 240VDC
Response Time
2 msec
Standards
CE, CSA Certified
Features
Output Short Circuit Protection, Overcircuit Protection, Reverse Polarity Protection
Body Material
Plastic
Max. Sensing Distance - Rectangular Photoelectric Sensor
4.9 m
IP Rating
IP67, IP69K
Max. Load Current
300 mA
Sensing Method
Polarized Retroreflective
Contact configuration
SPNO SSR
Contact Rating
300 mA at 240 Vac/dc
Maximum DC current
300 mA
Protection
Output short circuit, overcircuit and reverse polarity
Cable type
Polyvinyl Chloride (PVC)
Maximum AC current
300 mA
Enclosure Material
Fiberglass reinforced plastic
LED indicator
Power: yellow
Input voltage
24-240 Vac, 12-240 Vdc
Type
Photoelectric Sensor
Compliances
CE Marked
Operating Mode
Selectable Light On/Dark On
Includes Indicator Lights
Indicator Lights Included
Load Current - Maximum
300 mA
DC Voltage Rating
12-240V DC
Operating Temperature - Maximum
131 Degrees F
Sensing Distance - Minimum
152 mm
Switching Frequency
250 Hz
Orientation
Right Angle
AC Voltage Rating
24-240V AC
Series
Enhanced 50
Sensing Distance - Maximum
4.9 m
Output Circuit Relay Style
Solid State
Emitted Sensor Light
Red Light
Output Circuit Type
SPST
Operating Temperature - Minimum
-13 Degrees F
Electrical Installation Type
Prewired Cable
Style
Rectangular
NEMA Enclosure Rating
1, 12, 13, 2, 3, 4, 4X, 6

Description

Photoelectric Sensor, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On
