Eaton Power Supply, 100/240V AC, 24V DC, 480 W, 20 A, DIN Rail PSG480E24SMB - main

Power Supply, 100/240V AC, 24V DC, 480 W, 20 A, DIN Rail

  • Mfr # PSG480E24SMB

  • Zoro # G911208974

product price: $571.99
/ea
Free Shipping & Returns

Key Features

Input Voltage
100/240V AC
Output Voltage - Nominal
24V DC
Output Power - Rated
480 W
Current - Output
20 A
Mounting
DIN Rail
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PSG480E24SMB
Zoro #
G911208974
UPC #
-
Country of Origin
India

Dimensions

Overall Height
2.2 in
Overall Width
4.87 in
Overall Depth
4.6 in
Depth
4.6 in
Width
2.2 in
Height
4.87 in

Details

Item
Power Supply
Input Voltage
100/240V AC
Output Voltage - Nominal
24V DC
Output Power - Rated
480 W
Current - Output
20 A
Mounting
DIN Rail
Housing Material
Metal
Phase
Single
Power Supply Style
Switching
Output Voltage
24V DC
Status Indicator
Red LED
Style
Switching
IP Rating
IP20
Standards
CE, cUL, cULus/UL 60950-1, EN, IEC, RoHS Compliant
Hz
50/60 Hz
Series
PSG
Power Rating
480W
Case Material
Aluminum Case
Phase - Electrical
Single
Output Amps
20A
Certifications
cULus/UL 60950-1; IEC Rated; EN Listed; cUL Recognized
Compliances
CE Marked; German Safety
Current - Inrush
40 A
Mean Time Between Failures (MTBF)
7,000,000 hr
Maximum Efficiency @ 230V AC
93 %
Operating Temperature - Maximum
176 Degrees F
Start Up Time - Maximum
500 msec
Manufacturer Warranty
3 yr
Operating Temperature - Minimum
-13 Degrees F
Wire Connection Type
Screw Terminals

Description

DC Power Supply, Input Voltage 100 to 240V AC, Mounting DIN Rail, Series PSG, IP Rating IP20, Status Indicator Red LED, Standards CE, cUL, cULus/UL 60950-1, EN, IEC, RoHS Compliant
