Eaton Retroreflective Photoelectric Sensor, Bare Wire, Right Angle, Rectangular, Selectable Light On/Dark On, SPST 1450E-6513 - main

Retroreflective Photoelectric Sensor, Bare Wire, Right Angle, Rectangular, Selectable Light On/Dark On, SPST

  • Mfr # 1450E-6513

  • Zoro # G2083873

product price: $230.99
/ea
Free Shipping & Returns

Key Features

Width
1.81"
Depth
1.91"
Power Requirement - Rectangular Photoelectric Sensor
24 to 240V AC/12 to 240V DC
Standards
CE, CSA Certified
Operating Frequency
250 Hz
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
1450E-6513
Zoro #
G2083873
UPC #
-
Country of Origin
China

Dimensions

Width
1.81"
Depth
1.91"
Min. Object Size
Adjustable By Changing Gain
Height - Rectangular Photoelectric Sensor
88 mm
Length
3.46"
Depth - Rectangular Photoelectric Sensor
48 mm
Width - Rectangular Photoelectric Sensor
46 mm
Cable Length
2 m
Overall Height
46 mm
Product Length/Depth
3.46 in
Product Width
1.91 in
Product Height
1.81 in
Overall Width
49 mm
Overall Depth
88 mm

Details

Item
Photoelectric Sensor
Power Requirement - Rectangular Photoelectric Sensor
24 to 240V AC/12 to 240V DC
Standards
CE, CSA Certified
Operating Frequency
250 Hz
Power Requirement
24 to 240VAC/12 to 240VDC
Sensing Method
Retroreflective
Max. Sensing Distance
9m
Body Material
Plastic
Features
Output Short Circuit Protection, Overcircuit Protection, Reverse Polarity Protection
Response Time
2 msec
Max. Load Current
300 mA
IP Rating
IP67, IP69K
Electrical Connection
Bare Wire
Max. Sensing Distance - Rectangular Photoelectric Sensor
9 m
Operating Temp. Range
-25 Degrees to 55 Degrees C
Light Source
Red LED
Maximum DC current
300 mA
Contact Rating
300 mA at 240 Vac/dc
Compliances
CE Marked
Type
Photoelectric Sensor
Contact configuration
SPNO SSR
Maximum AC current
300 mA
Cable type
Polyvinyl Chloride (PVC)
LED indicator
Power: yellow
Enclosure Material
Fiberglass reinforced plastic
Input voltage
24-240 Vac, 12-240 Vdc
Protection
Output short circuit, overcircuit and reverse polarity
Operating Temperature - Maximum
131 Degrees F
Series
Enhanced 50
Emitted Sensor Light
Red Light
Operating Mode
Selectable Light On/Dark On
Load Current - Maximum
300 mA
DC Voltage Rating
12-240V DC
Electrical Installation Type
Prewired Cable
Style
Rectangular
Includes Indicator Lights
Indicator Lights Included
Output Circuit Type
SPST
NEMA Enclosure Rating
1, 12, 13, 2, 3, 4, 4X, 6
Switching Frequency
250 Hz
Sensing Distance - Maximum
9 m
Output Circuit Relay Style
Solid State
Orientation
Right Angle
Operating Temperature - Minimum
-13 Degrees F
Sensing Distance - Minimum
152 mm
AC Voltage Rating
24-240V AC

Description

Photoelectric Sensor, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On
