  13. Selector Switch, Illum, 3 Pos, Knob, 30mm
Eaton Selector Switch, Illum, 3 Pos, Knob, 30mm 10250ED1117-2KR - main

Selector Switch, Illum, 3 Pos, Knob, 30mm

  • Mfr # 10250ED1117-2KR

  • Zoro # G5226322

product price: $317.99
/ea
Free Shipping & Returns

Key Features

Size
30 mm
Basic Material
Metal
Type of Operator
Knob
Action
Maintained/Maintained/Maintained
Contact Form
2NO
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
10250ED1117-2KR
Zoro #
G5226322
UPC #
786680118753
Country of Origin
United States

Dimensions

Size
30 mm
Product Length/Depth
1 in
Product Diameter
1.38 in
Product Width
1 in
Product Height
1 in
Overall Depth
1 in
Manufacturer Warranty Length
1 yr
Overall Width
1 in
Overall Height
1 in
Panel Cutout Diameter
30 mm

Details

Item
Selector Switch
Basic Material
Metal
Type of Operator
Knob
Action
Maintained/Maintained/Maintained
Contact Form
2NO
Operator Head Material
Polymer
Cam
3
Color
Red
NEMA Rating
12, 13, 3, 3R, 4, 4X
Position
3
Bezel Material
Zinc
Bezel Color
Chrome
NEMA Contact Rating Designation
A600 / P600
IP Rating
IP68
Lamp Type
Incandescent
Lamp Voltage
6V AC
Switch Operation @ Position C
OX
Includes
Contact Block, Selector Switch Operator
Replacement Lamp
Mfr. No. 755
Switch Operation @ Position A
XO
Switch Operation @ Position B
OO
Standards
CE, CSA, UL Listed
Switch Operation @ Position D
No Fourth Position
Lamp Module Voltage
120V AC
Lamp Module Type
Transformer
Contact Rating
10A @ 660V AC/DC
DC Contact Rating
5 A @ 250 V
AC Contact Rating
10 A @ 660 V
Series
10250T
Contact configuration
2 NO
Number Of Positions
3
Compliances
CE Marked
Type
Selector switch
Certifications
UL Listed
Actuator color
Red
Illumination
Illuminated
Product Name
Eaton 10250T pushbutton
Contact Block Material
Metal
Hazardous Location Specification
Not Rated
Switch Function @ 2nd Position
Off
Number of Positions
3
NEMA Enclosure Rating
12, 13, 3, 3R, 4, 4X
Operator Head Color
Red
Switch Function @ 3rd Position
On
Operator Head Type
Short-Handled Knob
Lamp Voltage - Maximum
120 V AC
Operator Illumination
Illuminated
Switch Function @ 4th Position
No Fourth Position
Switch Function @ 1st Position
On

Description

Selector Switch, 30 mm, 3 Position, Maintained/Maintained/Maintained Action, 2NO Contact Form, Type of Operator Knob, Color Red, Operator Head Material Polymer, Basic Material Metal, Bezel Material Zinc, Bezel Color Chrome, Contact Rating 10A @ 660V AC/DC, NEMA Contact Rating Designation A600 / P600, NEMA Rating 12, 13, 3, 3R, 4, 4X, IP Rating IP68, Cam 3, Switch Operation @ Position A XO, Switch Operation @ Position B OO, Switch Operation @ Position C OX
