LED Directional Warrning Light

  • Mfr # ED3511A-WWG

  • Zoro # G805778347


product price: $99.65
/ea
Free Shipping & Returns

Key Features

Base Material
Aluminum
Lens Material
Polycarbonate
Lens Design
UV-Stabilized
Housing Material
Polycarbonate
Standards
CA T13, CE, R10, R65, RCM, RoHS Compliant
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ED3511A-WWG
Zoro #
G805778347
UPC #
758379111710
Country of Origin
Taiwan, Province of China

Dimensions

Overall Depth
1/2 in
Overall Height
1-1/8 in
Overall Length
3-5/16 in
Overall Width
3-3/10 in

Details

Item
LED Directional Warrning Light
Base Material
Aluminum
Lens Material
Polycarbonate
Lens Design
UV-Stabilized
Housing Material
Polycarbonate
Standards
CA T13, CE, R10, R65, RCM, RoHS Compliant
Mounting - Vehicle Lighting
Surface
Number of Heads
1
Flashes per Minute
36
Rating
SAE Class I
Wide Range - Vehicle Lighting
Perimeter Light
Features
All Electronics Embedded in Light Head
Includes
Mounting Hardware
Mount Type
Bolt
Current
1.4 A
Series
ED3511 Series
Light Color
Amber
Maximum Operating Temperature
122 Degrees F
Shape
Rectangular
Number of Flash Patterns
29
Vehicle Class
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13
Compatible Vehicle Type
Universal
Minimum Operating Temperature
-22 Degrees F
SAE Class Rating
SAE J595 Class 1
Electrical Connection
Blunt Cut Wires
Installation Type
Permanent
Wire Exit
Bottom
IP Rating
IP67
Number of Bulbs
16
Light Type
Perimeter Flashing Warning Light
Installation Location
Bumper, Grille, Hood, Side Mirror
Lens Color
Clear
Light Pattern
Flashing
Mount Style
Surface
Wattage
8.8 W
Lighting Technology
LED
Voltage
12 to 24V DC
Mounting - Vehicle Lighting_x
Surface

Description

LED Directional Warrning Light, Light Type Perimeter Flashing Warning Light, Light Color Amber, Wattage 8.8 W, Lens Color Clear, Shape Rectangular, Light Pattern Flashing, SAE Class Rating SAE J595 Class 1, Electrical Connection Blunt Cut Wires, Lighting Technology LED, Installation Type Permanent, Operating Voltage 12-24V DC, Overall Length 3 5/16 in, Overall Diameter Not Applicable, Overall Height 1 1/8 in, Overall Depth 1/2 in, IP Rating IP67, Compatible Vehicle Type Universal

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
