Heat Shrink End Caps, 3:1 I.D. Shrink Ratio, 2.95 in I.D. Before Shrinking, Black, 5.12 in
Mfr # HSEC-VAL-300-BK-10PK
Zoro # G916381528
product price:Â
$
96.59
/ea
Key Features
Shrink Ratio
3:1
Temp. Range
-55 Degrees C to 110 Degrees C
Min. Shrink Temp.
120 Degrees C
Standards
REACH, RoHS
Features
Adhesive Lining will Prevent Moisture Penetration, Forms Pressure-Tight Seal on Ends of Communication and Power Cables, Seals and Insulates in One Step, Includes Release Valve
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- HSEC-VAL-300-BK-10PK
- Zoro #
- G916381528
- UPC #
- -
- Country of Origin
- China
Dimensions
- Length
- 5.12 in
- Wall Thickness After Shrinking
- 0.14 in
- Use With Wire Size
- 3 in
Details
- Item
- Heat Shrink End Caps
- Shrink Ratio
- 3:1
- Temp. Range
- -55 Degrees C to 110 Degrees C
- Min. Shrink Temp.
- 120 Degrees C
- Standards
- REACH, RoHS
- Features
- Adhesive Lining will Prevent Moisture Penetration, Forms Pressure-Tight Seal on Ends of Communication and Power Cables, Seals and Insulates in One Step, Includes Release Valve
- I.D. Before Shrinking
- 2.95 in
- Color
- Black
- Adhesive Lined
- Yes
- Shrink Tubing Properties
- UV Light Resistant
- Dielectric Strength
- 15 kV
- Max. Temp. Rating
- 110 Degrees C
- Application
- High Voltage & Pressurized Cables
- Min. Temp. Rating
- -55 Degrees C
- I.D. After Shrinking
- 1.38 in
Description
Heat Shrink End Caps, I.D. Before Shrinking 2.95 in, I.D. After Shrinking 1.38 in, Temp. Range -55 Degrees C to 110 Degrees C, Shrink Ratio 3:1, Length 5.12 in, Use With Wire Size 3 in, Wall Thickness After Shrinking 0.14 in, Shrink Tubing Properties UV Light Resistant, Color Black, Adhesive Lined Yes, Application High Voltage & Pressurized Cables, Dielectric Strength 15 kV, Min. Shrink Temp. 120 Degrees C
