  6. Straight Blade Connector, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Screw Terminals, Black
Ericson Straight Blade Connector, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Screw Terminals, Black 1610-CW6P-BLK - main

Straight Blade Connector, 5-15R, 15 A, 125V AC, 2 Pole, 3 Wire, Screw Terminals, Black

  • Mfr # 1610-CW6P-BLK

  • Zoro # G3695545

product price:  $27.99
/ea
Sold in multiples of 2 for $55.98

Key Features

NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
1610-CW6P-BLK
Zoro #
G3695545
UPC #
782862681350
Country of Origin
United States

Details

Item
Straight Blade Connector
NEMA Receptacle Configuration
5-15R
Current Rating
15 A
Voltage Rating
125V AC
Phase
Single
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Wiring Style
Standard
Connection Orientation
Straight
Grounding
Grounded
Housing Color
Black
Cap Type
Flip-Up Cap
IP Rating
IP69K
Standards
CSA Certified to CSA C22.2 No.42, File 31943, ETL Listed to ANSI/UL 498, UL Listed to ANSI/UL 498, File E17740
Resistance Properties
Watertight
NEMA Configuration
NEMA 5-15
Device Type
Connector
ETL
ETL Listed to ANSI/UL 498
Sub Brand / Trademark
Perma-Tite
Case Qty
50
Ideal Application
Any environment that requires a watertight seal of a plug and connector to prevent water ingress. Applications range from a construction site to an entertainment venue and a drop down connector in a food processing plant during a Washdown procedure.
Poles / Wires
2P/3W
Blade Style
Straight
Environmental Rating
Watertight (IP69K)
CSA
CSA Certified to CSA C22.2 No.42, File 31943
cETL
cETL Listed to CSA C22.2 No. 42
UL
UL Listed to ANSI/UL 498, File E17740

Description

CONN-15AMP-125V STR BLADE BLK 1610-CW6P
