  9. Rectangular OEM Blower, 2500/3000 RPM, 1 Phase, Direct, Steel 1 Speed
Shop All OEM Specialty Blowers
Fasco

Rectangular OEM Blower, 2500/3000 RPM, 1 Phase, Direct, Steel 1 Speed

product price: $209.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Drive Type Direct
  • Full Load Amps 0.58/0.60
  • Housing Material Steel
  • Inlet Dia. 5 in
  • Number of Speeds 1
See all product information

Product Information

Dimensions

Inlet Dia. 5 in
Overall Height 8 7/8 in
Overall Width 7 3/4 in
Blower Wheel Diameter 4 3/4 in
Overall Depth 6 1/8 in
Outlet Width 1 3/4 in
Lead Length 4 in
Outlet Height 2 3/4 in
Blower Wheel Width 1 5/16 in
Inlet Diameter 5 in
Wheel Diameter 4 5/8 in

Details

Drive Type Direct
Full Load Amps 0.58/0.60
Housing Material Steel
Number of Speeds 1
Phase 1
Blower Item OEM Specialty Blower
Blower Outlet Shape Rectangular
With Flange No
Blower Motor Type Shaded Pole
Blower Voltage 208/230V AC
Blower Thermal Protection Auto
Blower Conduit Box No
Agency Compliance CSA Compliant, UL Recognized
Motor Enclosure Open
Item OEM Blower
Max. Inlet Temp. 400 Degrees F
Replaces Mfr. Model No. X38040363010, 7021-11054
Housing Color Natural
Housing Finish Metal
Wheel Type Forward-Curved
Motor Insulation Class B
Mounting Position All Position
Max. Ambient Temp. 104 Degrees F
Hz 50/60
RPM 2500/3000
Bearing Type Ball
Wheel Material Steel
Motor Type Shaded Pole
Maximum Inlet Air Temperature 400 Degrees F
Maximum Fan Speed 3,000 RPM
Application Furnaces
Electrical Connection Wire Leads
OEM Replacement Yes
Compatible with Brand Trane
Airflow @ 0.000 in SP 80 cfm
Nameplate Voltage 208-230V AC
Outlet Shape Rectangular
Current 0.6 A
Maximum Motor Speed 2,500 RPM
Motor Insulation Class B
Frequency 50/60 Hz
Maximum Static Pressure 2 in wc
Standards CSA Certified, UL Listed
Replacement For Manufacturer Model Number 7021-11054, X38040363010

Description

OEM Blower, Application Furnaces, Inlet Diameter 5 in, Outlet Diameter Not Applicable, Compatible with Brand Trane, Replacement For Manufacturer Model Number 7021-11054, X38040363010, Nameplate Voltage 208-230V AC, Phase 1, Current 0.6 A, Frequency 50/60 Hz, Electrical Connection Wire Leads, Motor Type Shaded Pole, Motor Insulation Class B, Maximum Fan Speed 3,000 RPM, Maximum Motor Speed 2,500 RPM, Maximum Inlet Air Temperature 400 Degrees F, Maximum Static Pressure 2 in wc
