Federal Signal Strobe Light, Clear, Strobe Tube, 24V DC, 80 FPM, 8 13/16 in Dia., Surface FSEX-HI-MOD - main

Strobe Light, Clear, Strobe Tube, 24V DC, 80 FPM, 8 13/16 in Dia., Surface

  • Mfr # FSEX-HI-MOD

  • Zoro # G4794139

product price:  $2,661.99
/ea
Free Shipping & Returns

Key Features

Color
Clear
Lamp Type
Strobe Tube
Power Source
Wire
Lamp Life
10,000 hr
Lens Material
Polycarbonate
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
FSEX-HI-MOD
Zoro #
G4794139
UPC #
782979232995
Country of Origin
United States

Dimensions

Height
11 3/8 in
Overall Diameter
8 13/16 in
Diameter
8 53/64 in
Depth
8 53/64 in
Width
8 53/64 in
Overall Length
11 3/8 in
Overall Width
8 13/16 in
Overall Depth
11 3/8 in

Details

Item
Strobe Light
Color
Clear
Lamp Type
Strobe Tube
Power Source
Wire
Lamp Life
10,000 hr
Lens Material
Polycarbonate
Flashes per Minute
80
Housing Material
Aluminum
Standards
CSFM Approved, cULus Listed, Marine Rated, UL Fire Listed, UL Listed
Features
Compatible with Multiple Systems, Conformal Coated PCBA, Synchronize with SSM Module
Voltage
24V DC
Operating Temp.
-31 Degrees to 150 Degrees F
Mounting
Surface
Lens Design
Fresnel
Current Drawn
1.9A DC
Light Output
2,000,000 Candela
Green Environmental Attribute
Does Not Contain Methylene Chloride
Rating
IP66, Marine, NEMA 4X
For Use With
Security, Chemical Plant, Alarm, Suppression Supervised Control Panel, Oil Rig, Mine, Fire Alarm, Refinery, Power Booster
Product Type
Strobe Light
Audible Alarm Type
Visual
NEMA Rating
NEMA 4X
Operating Temperature - Minimum
-31 Degrees F
Housing Color
Black
Mounting Style
Surface Mount
Brightness Selection
Fixed Brightness
Light Intensity
850 cd
Includes Mounting Hardware
No Mounting Hardware
Lens Shape
Dome
Lens Color
Clear
IP Rating
IP66, IP69K
Footprint Shape
Circle
Operating Temperature - Maximum
150 Degrees F
For Hazardous Location
Class I, Division 1, Class I, Division 2, Class II, Division 1
Light Operating Mode
Strobe
Operating Current
1.900 A @ 24V DC
Requires Base
Base Not Required
Control Protocol
Direct Wire
Lifespan
10,000 hr
Operating Voltage
24V DC

Description

Strobe Light, Color Clear, Lamp Type Strobe Tube, Flashes per Minute 80, Light Output 2,000,000 Candela, Lamp Life 10,000 hr, Lens Design Fresnel, Lens Material Polycarbonate, Housing Material Aluminum, Mounting Surface, Operating Temp. -31 Degrees to 150 Degrees F, Rating IP66, Marine, NEMA 4X, Power Source Wire, Current Drawn 1.9A DC, Width 8 53/64 in, Depth 8 53/64 in, Height 11 3/8 in, Voltage 24V DC
