  6. Warning Light, Amber, Strobe Tube, 24V DC, 80 FPM, 4 3/32 in Dia., 1/2 in NPT Pipe or Surface
Federal Signal Warning Light, Amber, Strobe Tube, 24V DC, 80 FPM, 4 3/32 in Dia., 1/2 in NPT Pipe or Surface FB24ST-024A - main

Warning Light, Amber, Strobe Tube, 24V DC, 80 FPM, 4 3/32 in Dia., 1/2 in NPT Pipe or Surface

  • Mfr # FB24ST-024A

  • Zoro # G4771057

product price:  $777.99
/ea
Free Shipping & Returns

Key Features

Lamp Type
Strobe Tube
Power Source
Wire
Lamp Life
10,000 hr
Lens Material
Polycarbonate
Flashes per Minute
80
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
FB24ST-024A
Zoro #
G4771057
UPC #
782979216391
Country of Origin
United States

Dimensions

Height
5 1/4 in
Overall Diameter
4 3/32 in
Depth
4 7/64 in
Width
4 7/64 in
Diameter
4 7/64 in
Overall Depth
5 1/4 in
Footprint Diameter
4 1/8 in

Details

Item
Warning Light
Color
Amber
Lamp Type
Strobe Tube
Power Source
Wire
Lamp Life
10,000 hr
Lens Material
Polycarbonate
Flashes per Minute
80
Housing Material
Polycarbonate
Standards
CSFM Approved, cUL Listed, cULus Listed, UL Listed
Features
Conformal Coated PCBA
Voltage
24V DC
Mounting
1/2 in NPT Pipe or Surface
Current Drawn
0.7A DC
Green Environmental Attribute
Does Not Contain Methylene Chloride
Lens Design
Fresnel
Rating
IP66, NEMA 4X
Light Output
1,000,000 Candela
Operating Temp.
-31 Degrees to 150 Degrees F
For Use With
Industrial, Fire Alarm, Emergency, Security
Product Type
Warning Light
Connection Type
Wire
Audible Alarm Type
Visual
NEMA Rating
NEMA 4X
Operating Temperature - Minimum
-31 Degrees F
Operating Temperature - Maximum
150 Degrees F
Lifespan
10,000 hr
Housing Color
Black
Light Intensity
1,000,000 cd
Brightness Selection
Fixed Brightness
Footprint Shape
Circle
Lens Color
Amber
Lens Shape
Dome
Includes Mounting Hardware
Mounting Hardware Included
IP Rating
IP66, IP67, IP69K
Light Operating Mode
Strobe
Operating Current
0.700 A @ 24V DC
Requires Base
Base Not Required
Light Source
LED
Control Protocol
Direct Wire
Mounting Style
Surface Mount
Operating Voltage
24V DC

Description

Warning Light, Color Amber, Lamp Type Strobe Tube, Flashes per Minute 80, Light Output 1,000,000 Candela, Lamp Life 10,000 hr, Lens Design Fresnel, Lens Material Polycarbonate, Housing Material Polycarbonate, Mounting 1/2 in NPT Pipe or Surface, Operating Temp. -31 Degrees to 150 Degrees F, Rating IP66, NEMA 4X, Power Source Wire, Current Drawn 0.7A DC, Width 4 7/64 in, Depth 4 7/64 in, Height 5 1/4 in, Voltage 24V DC
