Federal Signal Warning Light, Blue, LED, 120 to 240V AC, 60, 75, 90 FPM, Not Applicable Dia., Surface G-LED-AC-D-B - main

Warning Light, Blue, LED, 120 to 240V AC, 60, 75, 90 FPM, Not Applicable Dia., Surface

  • Mfr # G-LED-AC-D-B

  • Zoro # G5577638

product price:  $801.99
/ea
Free Shipping & Returns

Key Features

Lamp Type
LED
Power Source
Wire
Lamp Life
50,000 hr
Lens Material
Polycarbonate
Flashes per Minute
60, 75, 90
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
G-LED-AC-D-B
Zoro #
G5577638
UPC #
782979233558
Country of Origin
United States

Dimensions

Height
7 1/2 in
Width
5 15/64 in
Depth
5 15/64 in
Overall Width
5 7/32 in
Overall Length
5 7/32 in
Footprint Length
5 1/4 in
Footprint Width
5 1/4 in
Overall Depth
7 1/2 in

Details

Item
Warning Light
Color
Blue
Lamp Type
LED
Power Source
Wire
Lamp Life
50,000 hr
Lens Material
Polycarbonate
Flashes per Minute
60, 75, 90
Housing Material
Glass Reinforced Polyester
Standards
ABS, ATEX, CE, CSFM Approved, cUL Listed, cULus Listed, GOST, IECEx, INMETRO, UKCA, UL Listed
Features
Supervisory Diode
Voltage
120 to 240V AC
Lens Design
Fresnel
Rating
IP66
Includes
Dome Guard
Current Drawn
0.12 to 0.07A AC
Operating Temp.
-58 Degrees to 158 Degrees F
Mounting
Surface
Light Output
400 Lumens
For Use With
Industrial, Marine, Security, Signaling System, Control Panel
Product Type
Warning Light
Connection Type
TermiN/Al Block
Audible Alarm Type
Visual
NEMA Rating
NEMA 4X
Operating Current
0.070 to 0.120 A @ 120 to 240V AC
Control Protocol
User Operated
Light Operating Mode
Flashing, Rotating, Strobe
Operating Temperature - Minimum
-67 Degrees F
Requires Base
Base Not Required
Lens Color
Blue
Light Source
LED
Mounting Mechanism
Screw
Light Intensity
175 cd
Brightness Selection
Fixed Brightness
Includes Mounting Hardware
Mounting Hardware Included
Footprint Shape
Square
Lifespan
50,000 hr
Housing Color
Black
Mounting Style
Surface Mount
Lens Shape
Dome
IP Rating
IP66, IP69K
For Hazardous Location
Class I, Division 2, Class II, Division 2
Operating Temperature - Maximum
158 Degrees F
Operating Voltage
120 to 240V AC

Description

Warning Light, Color Blue, Lamp Type LED, Flashes per Minute 60, 75, 90, Light Output 400 Lumens, Lamp Life 50,000 hr, Lens Design Fresnel, Lens Material Polycarbonate, Housing Material Glass Reinforced Polyester, Mounting Surface, Operating Temp. -58 Degrees to 158 Degrees F, Rating IP66, Power Source Wire, Current Drawn 0.12 to 0.07A AC, Width 5 15/64 in, Depth 5 15/64 in, Height 7 1/2 in
