Shop FEDERAL SIGNAL

Warning Light w/Sound, LED, Amber, 24VDC

  • Mfr # AV1-LED-024A

  • Zoro # G7198466

product price:
$
304.99
/ea
Free Shipping & Returns

Key Features

Light Color
Amber
Standards
cUL Listed, cULus Listed, UL Listed
Lens Color
Amber
Mount Type
1, 2 in NPT
Lighting Technology
LED
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
AV1-LED-024A
Zoro #
G7198466
UPC #
782979227519
Country of Origin
United States

Dimensions

Overall Diameter
5 3/4 in
Overall Height
6-12/25 in
Overall Depth
6 1/2 in
Footprint Diameter
5 3/4 in

Details

Item
Warning Light
Light Color
Amber
Standards
cUL Listed, cULus Listed, UL Listed
Lens Color
Amber
Mount Type
1, 2 in NPT
Lighting Technology
LED
Lens Material
Fresnel Dome
Electrical Connection
Wire Leads
Mount Style
Surface Mount
Flashes per Minute
60, 75
Includes
Lens Gasket, Surface Mount Gasket
Lamp Life
60,000 hr
Lens Design
Fresnel
Mounting
Surface
Power Source
Wire
Features
Internal Buzzer Produces 85 dBA at 10 ft (95 dBA at 1m), PLC Compatible, Twist-Off Lens
Application
Signaling System
Voltage
24V DC
Housing Material
Polycarbonate
Housing Color
Black
Rating
Type 3R
Material
Fresnel Dome
Product Type
Warning Light
Connection Type
Wire Leads
Mounting Style
Surface Mount
NEMA Rating
NEMA 3R
Lifespan
50,000 hr
Water Resistance
Water Resistant
Requires Base
Base Not Required
Operating Temperature - Maximum
150 Degrees F
Mounting Mechanism
1/2 in NPT
Operating Current
0.270 A @ 24V DC
Includes Mounting Hardware
No Mounting Hardware
Control Protocol
Direct Wire
Lens Shape
Dome
Light Source
LED
Operating Temperature - Minimum
-31 Degrees F
Light Operating Mode
Flashing
Light Intensity
125 cd
Footprint Shape
Circle
Brightness Selection
Fixed Brightness
Minimum Operating Temperature
-31 Degrees F
Current
0.270 A @ 24V DC
Maximum Operating Temperature
150 Degrees F
Power Source - TS Only
Wire
Power Source - old
Wire

Description

Warning Light, Color Amber, Lamp Type LED, Flashes per Minute 60, 75, Lamp Life 60,000 hr, Lens Design Fresnel, Lens Material Fresnel Dome, Housing Material Polycarbonate, Mounting Surface, Operating Temp. -31 Degrees to 150 Degrees F, Power Source Wire, Current Drawn .27A AC, Width 5 19/25 in, Height 6 12/25 in
