Shop FILL-RITE

Flowmeter, Mechanical Fuel Transfer Meter, 3/4 in FNPT

  • Mfr # 807C
  • Zoro # G5373182
product price:
$
249.99
/ea
Free Shipping & Returns

Key Features

Resetable Cumulative Totalizer
100 gal
Length (In.)
8
Height (In.)
6
Flow Range
5 to 20 gpm
Connection Size
3/4 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
807C
Zoro #
G5373182
UPC #
089404110973
Country of Origin
United States

Dimensions

Length (In.)
8
Height (In.)
6
Connection Size
3/4 in
Width
6 in
Width (In.)
6
Length
4.9 in
Height
6 in
Connection Size (In.)
3/4 FNPT
Overall Width
6 in
Overall Height
6 in
Overall Length
4.9 in
For Pipe Size
3/4 in
Manufacturer Warranty Length
2 yr
Wire Rope Length
4.9 in

Details

Item
Flowmeter
Resetable Cumulative Totalizer
100 gal
Flow Range
5 to 20 gpm
Max. Pressure (PSI)
50
Max. Pressure
50 psi
Connection Type
FNPT
Flow Range (GPM)
5 to 20 gpm
GPM Max.
40 gpm
Shaft Material
Stainless Steel
Seal Material
Buna-N
Standards
CE Certified, cULus Listed
Housing Material
Aluminum
Product Type
Fuel Meter
Flowmeter Type
Paddlewheel
Flow Rate - Maximum
20 gpm
Display Type
Mechanical
Includes Flow Rate Adjustment Knob
Yes
Media Temperature - Minimum
-40 Degrees F
Includes Totalizer
Yes
Output Type
Standard Frequency Pulse
Wetted Material
Aluminum, Buna-N, Viton, Nickel, PTFE, Ryton, Stainless Steel
Includes Pressure Gauge
No
Operating Pressure - Maximum
50 psi
Rotor Material
PPS
Accuracy
+/-1%
Compatible Flow Material
Diesel, Gasoline, Solvents, Kerosene, Petroleum Fluids
Mounting Orientation
Universal
Flow Rate - Minimum
5 gpm
Media Temperature - Maximum
140 Degrees F
Pulse Rate
10 pulses/gal
Unit Of Measure
Gallons
Viscosity - Maximum
50 SUS
O-Ring Material
Buna-N

Description

The FILL-RITE 807C is a mechanical fuel transfer meter with a 3-digit display for measuring transferred fuel in gallon units. It is designed for flow rates from 5 to 20 gpm with +/-1% accuracy and uses 3/4 in FNPT connections. The meter is intended for use with diesel, gasoline, kerosene, solvents, and other petroleum fluids, and its cast-aluminum housing is paired with internal wetted materials including aluminum, Buna-N, Viton, nickel, PTFE, Ryton, and stainless steel.

Key Features:

  • Mechanical display: 3-digit mechanical register shows batch totals up to 99.9 gallons.
  • Totalizer included: 5-digit non-resettable counter tracks total transferred volume over the life of the meter.
  • Accuracy: Measures within +/-1%.
  • Flow range: Operates from 5 to 20 gpm.
  • Connection: 3/4 in FNPT ports for fuel transfer system installation.
  • Housing material: Aluminum body construction.
  • Compatible fluids: Diesel, gasoline, kerosene, solvents, and petroleum fluids.
  • Operating limits: Maximum pressure 50 psi; media temperature range -40 to 140 degrees F.
  • Mounting orientation: Universal mounting configuration.
  • Flow rate adjustment knob: Included.
