  5. IR Cam, 464x348IR Res, 24x18FOV
No Product Image Available

IR Cam, 464x348IR Res, 24x18FOV

  • Mfr # FLIR E86-24

  • Zoro # G801006659

product price:  $18,478.99
/ea
Free Shipping & Returns

Key Features

Emissivity
Adjustable 0.01 to 1.00
Detector Resolution - Infrared
464 × 348 px
Ambient Temp. Range
5 Degrees to 122 Degrees F
Image Notation
Text, Voice
Temp. Accuracy (C) - Infrared
+/-2 Degrees C or +/-2% of the Reading
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
FLIR E86-24
Zoro #
G801006659
UPC #
845188022679
Country of Origin
Estonia

Dimensions

Manufacturers Warranty Length
2 yr Parts and Labor
Manufacturer Warranty Length
2 yr
Display Size
4 in

Details

Item
Infrared Camera
Emissivity
Adjustable 0.01 to 1.00
Detector Resolution - Infrared
464 × 348 px
Ambient Temp. Range
5 Degrees to 122 Degrees F
Image Notation
Text, Voice
Temp. Accuracy (C) - Infrared
+/-2 Degrees C or +/-2% of the Reading
Temp. Range (F) - Infrared
-4 to 248 Degrees F, 572 to 2732 Degrees F
Focus Method
Auto, Manual
Thermal Sensitivity - IR Camera
40 mK
Visual Light Resolution
5 MP
Includes
Battery Charger, Cables (USB 2.0 A to USB Type-C), Flir Thermal Studio Starter, Front Lens Cap, Hard Carrying Case, Infrared Camera Lens, Lanyards, License Card, Power Supply, USB Type-C to HDMI, USB Type-C to USB Type-C
Thermal and Visible Light Blending
Yes
Frame Rate - IR Camera
30 Hz
Picture In Picture
Yes
Multiple Lens Option
Yes
Standards
EN/UL/CSA/PSE 60950-1, IEC/EN 60950-1, IEC/EN 62368-1
Temp. Accuracy (F) - Infrared
+/-3.6 Degrees For +/-2% of the Reading
Special Features
4 in Touchscreen, Built In GPS, Image Sktech, METERLiNK to FLIR Meters, UltraMax (Super-Resolution), Voice Annotations
Drop Tested
2 m
Charger Replacement
627L67
NIST Certified
No
Ambient Temp. Range (F)
5 Degrees to 122 Degrees
Removable Memory Card
8GB MicroSD
Wireless
Yes
Data Logging - Instrument
Yes
Alarm
No
Display - IR Camera
4.0 in Touch Screen Color LCD
File Formats
CSQ
Focus Distance - Infrared
Minimum 0.15 m
Spectral Response - Infrared
7.5 to 14 micron m
Field of View - IR Camera
24 Degrees Horizontal × 18 Degrees Vertical
Safety Rating
EN/UL/CSA/PSE 60950-1
Temp. Range (C) - Infrared
-20 to 120 Degrees C, 300 to 1500 Degrees C
Display Resolution - IR Camera
4", 464 × 348 Pixel Touchscreen LCD with Auto-rotation
Laser Sighting
Yes
Articulating Lens
No
Included Charger
627L67
Item - Infrared Camera
Infrared Camera
Product Type
Infrared Camera
Maximum Emissivity Setting
1.00
Series
FLIR Exx
Number of Batteries Required
2
Alert Type
Digital Display, Sound
Interface
SD Card, USB, Wireless
Infrared Resolution
464 x 348
Battery Chemistry
Lithium Ion
Lens Angles Included
24 Degrees
Battery Run Time
2.5 hr
Minimum Emissivity Setting
0.01
Frame Rate
30 Hz
Field of View
24 Degrees x 18 Degrees
Display Resolution
640 x 480
Minimum Operating Temperature Degrees F
5 Degrees F
Minimum Temperature Measured Degrees C
-20 Degrees C
Accuracy Degrees F
+/-2.0% of Reading or +/-3.6 Degrees F Whichever is Greater
Data Transfer Type
Wired, Wireless
Maximum Temperature Measured Degrees F
2,732 Degrees F
Minimum Focus Distance
0.15 m
Batteries Included
Yes
Portability
Handheld
Maximum Temperature Measured Degrees C
1,500 Degrees C
Laser Sighting Type
Circular
Thermal Sensitivity
40 mK
Features
Data Logging, Image Notation, Image Sketching, Multi Spectral Dynamic Imaging (MSX(R))
Auto Power Off
Yes
Intrinsic Safety
Not Specified Intrinsically Safe
Maximum Operating Temperature Degrees F
122 Degrees F
Battery Voltage
3V
Calibration Certificate Type
Available Separately
Digital Display Screen Type
LCD Touchscreen
Minimum Temperature Measured Degrees F
-4 Degrees F
Accuracy Degrees C
+/-2.0% of Reading or +/-2.0 Degrees Whichever is Greater
Temperature Alerts
High Temperature, Low Temperature, Normal Body Temperature
Emissivity Adjustability
Adjustable

Description

Infrared Camera, Temperature Alerts High Temperature, Low Temperature, Normal Body Temperature, Frame Rate 30 Hz, Visual Light Resolution 5 MP, Calibration Certificate Type Available Separately, Alert Type Digital Display, Sound, Data Transfer Type Wired, Wireless, Digital Display Screen Type LCD Touchscreen, Emissivity Adjustability Adjustable, Maximum Emissivity Setting 1.00, Minimum Emissivity Setting 0.01, Thermal Sensitivity 40 mK, Minimum Focus Distance 0.15 m
