Plate Caster, Rigid, Polyurethane, 171mm H

Mfr # GDSB-100ARF-LUD
Zoro # G711745273

95.39

Key Features

Wheel Dia.

100 mm

Mounting Bolt Dia.

7 mm

Caster Frame Material

Aluminum

Caster Sub-Type

Rigid

Features

Fine Shock Absorption Function With Special Rubber (Select Between A65 and A75), Special Wheel Axle for Reinforce of Smooth Rolling

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: GDSB-100ARF-LUD
Zoro #: G711745273
UPC #: -
Country of Origin: Korea, Republic of

Dimensions

Wheel Dia.: 100 mm
Mounting Bolt Dia.: 7 mm
Mounting Height: 171 mm
Wheel Width: 30 mm
Mounting Plate Size: 2.87 in x 2.87 in

Details

Caster Frame Material: Aluminum
Caster Sub-Type: Rigid
Features: Fine Shock Absorption Function With Special Rubber (Select Between A65 and A75), Special Wheel Axle for Reinforce of Smooth Rolling
Standards: RoHS Compliant
Number of Mounting Holes: 4
Load Rating: 220 lb
Caster Brake Type: No Brake
Number of Wheels: 1
Item: Plate Caster
Inside Bolt Hole Spacing: 2.28 in x 2.28 in
Caster Mounting Type: Plate
Wheel/Tread Hardness Rating: Firm
Wheel Bearing Type: Ball
Operating Temperature Range: 14 Degrees to 194 Degrees F
Swivel Raceway Type: Double Ball
Wheel/Tread Material: Polyurethane
Frame Color: Blue
Wheel Core Material: Aluminum
Wheel Hardness Rating: 90 Shore A
Load Capacity - Maximum: 220 lb
Caster Features: Shock-Absorbing

Description

Rigid, Plate Caster, Load Rating 220 lb, Wheel Dia. 100 mm, Wheel Width 30 mm, Wheel/Tread Material Polyurethane, Wheel Core Material Aluminum, Number of Wheels 1, Caster Brake Type No Brake
