  11. Class 2 Transformer, 100 VA, NEMA 1, 24V AC, 120/240/277/480V AC
Functional Devices-Rib Class 2 Transformer, 100 VA, NEMA 1, 24V AC, 120/240/277/480V AC PSH500A - main

Class 2 Transformer, 100 VA, NEMA 1, 24V AC, 120/240/277/480V AC

  • Mfr # PSH500A

  • Zoro # G6458532

product price: $692.99
/ea
Free Shipping & Returns

Key Features

Input Voltage - Transformer
120/240/277/480V AC
Output Voltage
24V AC
Power Rating
100 VA
Phase
1
Mounting - Transformer
Wall
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PSH500A
Zoro #
G6458532
UPC #
-
Country of Origin
United States

Dimensions

Overall Height
12.13 in
Overall Width
12.12 in
Overall Depth
6 in
Circuit Breaker Size
4 A

Details

Item
Class 2 Transformer
Input Voltage - Transformer
120/240/277/480V AC
Output Voltage
24V AC
Power Rating
100 VA
Phase
1
Mounting - Transformer
Wall
Hz - Electrical
50/60 Hz
NEMA Enclosure Rating
NEMA 1
Secondary Connection
Screw Terminals
Standards
CE, OSHPD Seismic Certified, RoHS, UL Class 2, UL Listed
Primary Connection
Screw Terminals
Includes
10A Main Breaker Switch, 120V AC Convenience Outlets, Finger-Safe Terminals, LED Power Indicator, On/Off Control
Enclosure Style - Transformer
Enclosed
Protective Device
Circuit Breaker
Enclosure Finish
Powder Coated
Enclosure Type
Enclosed
Approvals
Class 2 (UL Approved UL5085-3), UL916, C-UL, CE
Output
5 Ungrounded, Isolated, 100 VA, Class 2, 24 Vac Outputs. Terminals accept 12-26 AWG wire
24 Vac ON/OFF
On / Off Switch & Breaker
Secondary Output Voltage vs. Load
24.0 V @ 1 Amp 23.0 V @ 2 Amp 21.8 V @ 3 Amp 21.1 V @ 4 Amp
Full Load Primary Current
4.66 A @ 120 Vac 2.41 A @ 240 Vac 2.06 A @ 277 Vac 1.17 A @ 480 Vac
Standby Wattage
48.515 W @ 120 Vac 48.699 W @ 240 Vac 49.564 W @ 277 Vac 48.255 W @ 480 Vac
Transformer
One (1) 500 VA
5 Secondaries
24 Vac, with LED Indicators 4 Amp breaker for each output
Ambient Temperature Derating
4A up to 40° C ; 3A up to 50° C ; 2A up to 55° C
Number of Outputs
2
Wire Connection Type
Screw Terminals
Number of Convenience Outlets
1
Housing Material
Metal
Overcurrent Protection
Circuit Breaker
Operating Temperature - Maximum
131 Degrees F
Includes On/Off Switch
Individual Output On/Off Switch
Temperature Rise
Not Rated

Description

Class 2 Transformer, (5) 100 VA Rating, Input Voltage 120/240/277/480VAC, Output Voltage 24VAC, Multi Mounting, Protective Device Circuit Breaker, Primary Connection Screw Terminals, Secondary Connection Screw Terminals, 1 Phase, 50/60 Hz, Not Rated Temp. Rise, Enclosed Enclosure Type, Enclosure Rating NEMA 1, Enclosure Finish Powder Coated, Height 12.13 In., Depth 6.00 In., Width 12.12 In.
